The Dolphin DC-500F Super B Connector Manual Crimping Tool is a specialised hand crimping tool designed for secure wire connections in low-voltage electrical, telecommunications, security and alarm installations. Supporting 24–16 AWG wire applications, the DC-500F is compatible with Dolphin Super B Connectors, providing a practical solution for professional cable termination, wire splicing and maintenance work.
Designed for manual operation, the DC-500F features a side-loading crimping mechanism that accommodates compatible Dolphin Super B connectors. Its straightforward hand-operated design allows technicians and installers to complete crimping tasks without powered equipment.
The DC-500F works with both plain and sealant-filled Super B Connectors, making it suitable for a range of wiring applications where dependable connector installation is essential.
Main Features
-
Manual crimping operation: Hand-operated tool for installing Dolphin Super B Connectors.
-
24–16 AWG wire range: Designed for the manufacturer's specified Super B connector wire range.
-
Side-loading design: Allows connectors to be inserted from the side of the tool.
-
Broad connector compatibility: Supports DC-1000-P, DC-100-P, DC-1000-S and DC-100-S.
-
Plain and sealant-filled connectors: Compatible with both connector versions.
-
No electrical power required: Suitable for manual installation and servicing.
-
Versatile applications: Designed for low-voltage security, alarm, telecommunications and control wiring installations.
Detailed Technical Specifications
|
Specification
|
Details
|
|
Brand
|
Dolphin Components
|
|
Model
|
DC-500F
|
|
Product Code
|
DC-500F
|
|
Product Description
|
Super B Connector Manual Crimping Tool
|
|
Tool Type
|
Manual crimping tool
|
|
Crimping Mechanism
|
Side-loading, hand-operated
|
|
Specified Wire Range
|
24–16 AWG
|
|
Compatible Connector Family
|
Dolphin Super B Connectors
|
|
Compatible Connector Codes
|
DC-1000-P, DC-100-P, DC-1000-S, DC-100-S
|
|
Connector Variants
|
Plain and sealant-filled
|
|
Typical Applications
|
Low-voltage wiring, telecommunications, security and alarm systems
|
Compatible Dolphin Super B Connectors
|
Connector Code
|
Description
|
|
DC-1000-P
|
Plain white Super B Connectors, 1,000-piece pack
|
|
DC-100-P
|
Plain white Super B Connectors, 100-piece pack
|
|
DC-1000-S
|
Sealant-filled blue Super B Connectors, 1,000-piece pack
|
|
DC-100-S
|
Sealant-filled blue Super B Connectors, 100-piece pack
|
The DC-500F is a manual crimping tool. The DC-4141 is the separate ratchet crimping tool model for the same connector family.
What's Included in the Box
- 1 × Dolphin DC-500F Super B Connector Manual Crimping Tool
Connector packs and additional accessories are not included.
Practical Use Scenarios
Security and alarm system installations: Crimping compatible Super B Connectors during low-voltage alarm wiring installation or maintenance.
Telecommunications wiring: Connecting compatible small-gauge conductors in telecommunications and communications infrastructure.
Low-voltage control systems: Supporting connector installation for compatible control wiring applications.
Electrical maintenance and servicing: Providing a manually operated crimping option for replacing or installing Dolphin Super B wire connectors.
Professional installation work: A useful hand tool for technicians working with the specified Dolphin connector range.
Brand Description – Dolphin Components
Dolphin Components is a manufacturer of wire connectors and installation tools designed for telecommunications, security, low-voltage control and electrical wiring applications. Its Super B Connector range provides practical solutions for connecting and splicing wires, supported by dedicated manual and ratchet crimping tools.
Warranty Information
No warranty is specified for this product.
Datasheets & Downloadable Resources
Excellence for the Australian and New Zealand Market
The Dolphin DC-500F Manual Crimping Tool offers a practical solution for Australian and New Zealand telecommunications, security and low-voltage installation professionals working with compatible Dolphin Super B Connectors.
-
Australian and New Zealand applications: Suitable for relevant low-voltage wiring and connector installation tasks, subject to applicable installation requirements.
-
Compatibility: Supports the specified Dolphin Super B Connector range used in security, communications and control wiring.
-
Manufacturer documentation: Dolphin provides technical instructions and product information to support proper tool operation.
-
Quality and compliance: Australian and New Zealand product-specific certification or regulatory approval has not been verified. Installers should confirm applicable requirements before use.
-
Manufacturer support: Technical product information is available through Dolphin Components.
Frequently Asked Questions (FAQs)
1. What is the Dolphin DC-500F Super B Connector Manual Crimping Tool used for?
The Dolphin DC-500F is a manual crimping tool designed for installing Super B Wire Connectors in low-voltage control, telecommunications, security and alarm wiring applications.
2. What wire sizes are supported by the Dolphin DC-500F?
The Dolphin DC-500F is listed in the manufacturer's tool catalogue for 24–16 AWG wiring. The manufacturer's operating instructions also discuss certain 26–16 AWG wire applications, depending on the connector and conductor configuration.
3. Which connectors are compatible with the Dolphin DC-500F?
The Dolphin DC-500F accommodates four Super B Connector product codes: DC-1000-P, DC-100-P, DC-1000-S and DC-100-S.
4. Can the Dolphin DC-500F crimp sealant-filled Super B Connectors?
Yes. The Dolphin DC-500F is compatible with the DC-1000-S and DC-100-S sealant-filled Super B Connectors, as well as the corresponding plain connector variants.
5. Does the Dolphin DC-500F require electricity or batteries?
No. The Dolphin DC-500F is a manually operated crimping tool that does not require electricity or batteries.
6. Is the Dolphin DC-500F suitable for telecommunications installations?
Yes. The Dolphin DC-500F is intended for compatible connector installation in telecommunications, communications and other low-voltage wiring applications.
7. What is the difference between the Dolphin DC-500F and DC-4141?
The DC-500F is a manual crimping tool, while the DC-4141 is a ratchet crimping tool. Both are designed for the specified Dolphin Super B Connector range.
8. How do I use the Dolphin DC-500F crimping tool?
Insert the wires into a compatible Super B Connector following the manufacturer's wire preparation instructions. Place the connector into the appropriate side-loading slot of the DC-500F, squeeze the handles and complete the recommended crimps near the centre of the connector.
9. Is wire stripping required when using the Dolphin DC-500F?
Not always. According to Dolphin's instructions, certain small-gauge solid wires may be installed without stripping. For 16 AWG and stranded wires, specific wire preparation is required. Follow the instructions for the connector and wire configuration.
10. Is the Dolphin DC-500F suitable for Australian and New Zealand installers?
The Dolphin DC-500F can be used for compatible Super B Connector installation tasks in Australia and New Zealand, provided the intended application meets applicable electrical installation requirements.
