The Paradox PDX‑PCS265MQ LTE MQTT Communicator is a powerful cellular communication module designed for Paradox alarm systems. It enables MQTT protocol reporting over LTE networks and remote interaction via the BlueEye mobile app (excluding Insite Gold). It provides reliable back‑to‑base connectivity using Paradox IPC10 receivers with dual SIM redundancy and robust encrypted communications, making it ideal for modern alarm monitoring and control in residential and commercial environments.
What’s Included in the Box
Main Features
-
MQTT Protocol on LTE: Seamless alarm reporting to monitoring stations via Paradox IPC10.
-
BlueEye Mobile App Support: Arm/disarm and receive push alerts (Insite Gold NOT supported).
-
Dual SIM Support: Two SIM slots for LTE provider redundancy (Telstra/Optus/Vodafone).
-
SMS Alerts: End‑user setup for SMS notifications via touchscreen keypad.
-
Installer Remote Programming: BabyWare support for remote configuration.
-
Encrypted Communication: 128‑bit AES encryption for secure data transmission.
-
Tamper Protection: Dual tamper switches (wall and cover removal).
-
Wide Compatibility: Works with EVO Series, SP65, SP6000+, MG5050+ panels.
Detailed Specifications
| Specification |
Details |
| Model |
PDX‑PCS265MQ |
| Network Support |
LTE ONLY |
| Frequency Bands |
B1 / B3 / B5 / B7 / B8 / B20 / B28 / B40 / B41 / B38 |
| Providers |
Telstra, Optus, Vodafone |
| Antenna Bandwidth |
5 bands, wideband |
| RF Power |
Class 4 (2W) @ 850/1900 MHz, Class 2 (1W) @ 1800/1900 MHz |
| Voltage Input |
12 VDC Nominal |
| Current Consumption |
60 mA (Standby), 300 mA (Max) |
| Encryption |
128‑bit AES |
| SMS Protocol |
7‑bit GSM or 16‑bit UCS2 |
| SIM Cards |
Dual LTE SIM Support |
| Operating Temp. |
‑20 °C to 50 °C |
| Humidity |
0–90% Non‑Condensing |
| Dimensions |
208 × 75 × 20 mm |
| Certifications |
II EN 50131‑10 ATS Category SP5, AS/CA S042.1‑2022, AS/CA S042.4‑2022 |
| Panel Interface |
4‑Wire Serial Connection |
Warranty Information
-
Standard Manufacturer Warranty: Covers defects in materials and workmanship (refer to included warranty card for period and terms).
-
Warranty Service: Handled directly by Paradox authorised support centres in Australia and New Zealand.
Brand Description
Paradox Security Systems is an industry‑leading manufacturer of advanced intrusion detection and alarm communication technologies. Renowned for innovation, quality engineering, and rigorous testing, Paradox supports installers and end users with secure, reliable solutions trusted worldwide.
Practical Use Scenarios
-
Commercial Sites: Reliable MQTT alarm reporting for retail stores, offices, and warehouses where IP connection may be limited.
-
Remote Properties: LTE connectivity ensures continued alarm reporting and control without fixed internet.
-
Managed Security: Installers use BabyWare for remote diagnostics and programming.
-
Residential Security: Homeowners receive push notifications and can arm/disarm via BlueEye.
Excellence for the Australian and New Zealand Market
The PDX‑PCS265MQ LTE MQTT Communicator meets Australian and New Zealand regulatory requirements and quality standards including AS/CA S042.1‑2022 and AS/CA S042.4‑2022. It supports local LTE bands (including B28) across major Australian carriers (Telstra, Optus, Vodafone) for robust network coverage. All units are sourced from authorised Paradox distributors with valid warranties and direct brand support within Australia and New Zealand.
FAQs – Paradox PDX‑PCS265MQ
Q: What network bands does the Paradox PDX‑PCS265MQ support for LTE connectivity?
A: The PDX‑PCS265MQ supports multiple LTE frequency bands including B1, B3, B5, B7, B8, B20, B28, B38, B40, and B41 for wide carrier compatibility.
Q: Can the Paradox PDX‑PCS265MQ send alarms via SMS?
A: Yes, the PDX‑PCS265MQ supports SMS alerts where end users can configure mobile numbers using a touch‑screen keypad.
Q: Is the Paradox PDX‑PCS265MQ compatible with Insite Gold?
A: No, the PDX‑PCS265MQ supports the BlueEye mobile application only; Insite Gold is not supported.
Q: Does the Paradox PDX‑PCS265MQ provide encrypted communication?
A: Yes, the PDX‑PCS265MQ uses 128‑bit AES encryption for secure communications.
Q: Can installers program remotely with the Paradox PDX‑PCS265MQ?
A: Yes, the PDX‑PCS265MQ supports remote installer access using BabyWare.
Q: What alarm panels are compatible with the Paradox PDX‑PCS265MQ?
A: The PDX‑PCS265MQ is compatible with EVO Series, SP65, SP6000+, and MG5050+ alarm panels.
