The PDX-DCTXP2 Wireless Door Contact is designed for on-frame installation on doors and windows, providing dependable perimeter protection in residential and commercial environments. Operating on 433MHz, it integrates seamlessly with compatible Paradox wireless control panels and receivers.
This model offers 2 independent zones, each with its own serial number. Zone 1 features a high-sensitivity reed switch with included magnet, while Zone 2 provides a universal transmitter input (N.O./N.C.), allowing connection to an external wired device.
Engineered for stability within Paradox wireless networks, the DCTXP2 includes anti-tamper protection, live supervision, and battery level monitoring. Its powerful magnet ensures reliable activation at gaps up to 10mm, supporting consistent detection performance.
What’s Included in the Box
Main Features
-
433MHz wireless frequency
-
2 independent zones (each with unique serial number)
-
Zone 1: High-sensitivity reed switch (magnet included)
-
Zone 2: Universal transmitter input (N.O./N.C.)
-
Anti-tamper switch
-
Live supervision and battery level monitoring
-
Powerful magnet operation up to 10mm gap
-
Designed for door and window frame installation
Detailed Specifications
-
Product Code: PDX-DCTXP2
-
RF Frequency: 433 MHz
-
Zones: 2
-
Power Supply: 2 × AAA alkaline batteries
-
Battery Life: Up to 4 years (based on typical usage)
-
Wireless Range (Typical Indoor):
-
Operating Temperature: -20°C to 50°C (-4°F to 122°F)
-
Dimensions: 11 × 3.2 × 2.5 cm
-
Tamper Protection: Cover tamper switch
-
Supervision: Live supervision with battery monitoring
Compatibility
The PDX-DCTXP2 is compatible with:
-
Paradox MG6250
-
Paradox MG5000
-
Paradox MG5050
-
Paradox RTX3 Wireless Expansion Module
-
Paradox K32LX / K641LX Keypads with built-in transceiver
-
Paradox RX1 Wireless Receiver
Warranty Information
Supplied with manufacturer-backed warranty coverage. Warranty and technical support are handled through authorised Paradox distribution channels in accordance with official policies.
About the Brand – Paradox
Paradox Security Systems is an internationally recognised manufacturer of advanced alarm and security technologies. Known for robust wireless communication stability and flexible system design, Paradox products are widely trusted for residential and commercial security installations.
SKU
PDX-DCTXP2
Practical Use Scenarios
-
Wireless protection for entry doors
-
Securing residential windows
-
High-traffic commercial door monitoring
-
Expanding wireless zones without running cables
-
Integrating external wired contacts via Zone 2 input
Datasheets & Downloadable Resources
Excellence for the Australian and New Zealand Market
The Paradox PDX-DCTXP2 is well-suited for Australian and New Zealand installations requiring reliable wireless perimeter protection. Sourced through authorised representatives, this device ensures genuine quality, compliant operation within approved frequency ranges, and dependable warranty handling. Its supervised wireless communication and tamper protection provide professional-grade performance suited to local residential and commercial security standards.
Frequently Asked Questions (FAQs)
Q1: What frequency does the PDX-DCTXP2 operate on?
The PDX-DCTXP2 operates on 433MHz wireless frequency.
Q2: How many zones does the PDX-DCTXP2 support?
The PDX-DCTXP2 supports 2 independent zones, each with its own serial number.
Q3: Can the PDX-DCTXP2 connect to an external wired device?
Yes, Zone 2 on the PDX-DCTXP2 provides a universal transmitter input (N.O./N.C.) for connecting an external wired device.
Q4: What is the typical wireless range of the PDX-DCTXP2?
The PDX-DCTXP2 typically offers up to 70m indoor range with MG5000/MG5050/RTX3 and up to 30m with MG6250 (installation dependent).
Q5: Does the PDX-DCTXP2 include tamper protection?
Yes, the PDX-DCTXP2 includes an anti-tamper switch for added security.
Q6: How is the PDX-DCTXP2 powered?
The PDX-DCTXP2 is powered by 2 × AAA alkaline batteries with up to 4 years typical battery life
