The Uniview PKC2641-Z28-P is a high-performance 4MP License Plate Recognition (LPR) bullet camera engineered for vehicle monitoring and gate control applications. Equipped with a 1/1.8" CMOS sensor, advanced image enhancement (Wise-ISP), and real-time video capture at up to 60 fps, this camera excels in all lighting conditions. Designed with integrated warm light LEDs and a 2.8–12 mm motorised lens, it delivers wide field-of-view flexibility and enhanced image clarity for license plate recognition at various ranges and speeds.

With built-in vehicle and license plate recognition algorithms, the PKC2641-Z28-P supports multiple countries' standards and can manage allowlists/blocklists for automated access control. Rated IP67 and IK10, this robust camera withstands harsh Australian outdoor environments, while edge storage support up to 512GB allows reliable local video capture.

What’s Included in the Box

• Uniview PKC2641-Z28-P LPR Bullet Camera

• 3-axis mounting bracket with junction box

• Integrated warm light LED module (built-in)

• Quick installation accessories and user guide

• Cable gland and weatherproof sealing components

Main Features

• 4MP 1/1.8" progressive scan CMOS sensor with real-time video at 60 fps

• Wise-ISP technology for enhanced imaging in diverse light conditions

• 2.8–12 mm motorised varifocal lens with horizontal FOV: 106.4°–50.3°

• Integrated 4 × warm light LEDs with 50 m illumination distance

• License plate recognition for vehicles up to 80 km/h

• Built-in allowlist/blocklist management (up to 20,000 records)

• Open barrier logic configurable for secure automation

• Up to 512GB edge storage (MicroSD) with ANR support

• H.265/H.264 compression and triple-stream encoding

• Rugged IP67 & IK10 protection with wide operating range –40 °C to +60 °C

• 3D DNR, digital defog, 120 dB WDR, BLC and HLC

Detailed Specifications

Warranty Information

The Uniview PKC2641-Z28-P comes with standard warranty support when sourced through authorised Australian distribution. For accurate warranty duration and terms, confirm with your local distributor at the time of purchase. Uniview’s robust service and firmware support are available across ANZ regions.

Brand Description

Uniview is a globally recognised manufacturer of high-performance surveillance systems, renowned for their intelligent traffic solutions and AI-powered analytics. Their LPR cameras are trusted in thousands of deployments worldwide for their accuracy, performance, and reliability across roadways, carparks, and access control points.

Practical Use Scenarios

1. Gated Communities or Apartment Complexes – Manage entry automatically using plate-based barrier triggers.

2. Commercial Facility Entrances – Enforce access control by verifying allowlisted vehicles.

3. Warehouse & Industrial Site Gates – Monitor and log plate numbers for vehicle activity and security compliance.

4. Carparks or Shopping Centres – Enhance customer experience with seamless access, exit tracking, and analytics.

5. Traffic Lanes or Suburban Roads (≤80 km/h) – Capture vehicle data for record-keeping or regulatory enforcement.

Downloads / Datasheets

• Datasheet

  Quick Guide

Excellence for the Australian and New Zealand Market

The Uniview PKC2641-Z28-P is sourced exclusively via Australian-authorised distribution, ensuring that it meets Australian performance, safety, and environmental standards. With IP67 waterproofing, IK10 impact resistance, and high tolerance to extreme temperatures (–40 °C to +60 °C), it is ideal for the varied climates of both Australia and New Zealand. Local warranty support and compatibility with infrastructure in the region further reinforce its suitability for professional deployments.

FAQs (Model Code: PKC2641-Z28-P)

Q1: What resolution and frame rate does the PKC2641-Z28-P support?
A1: It supports up to 4MP (2688 × 1520) resolution at a maximum of 60 fps for real-time video clarity.

Q2: Can the PKC2641-Z28-P recognise number plates at night?
A2: Yes, it features integrated warm light LEDs and advanced plate recognition algorithms that enable clear identification even in complete darkness.

Q3: What is the maximum vehicle speed supported for plate capture with PKC2641-Z28-P?
A3: The camera supports license plate recognition at vehicle speeds up to 80 km/h on regular roads and up to 30 km/h for entrance/exit lanes.

Q4: Does the PKC2641-Z28-P support barrier integration?
A4: Yes, the camera offers relay outputs and customisable open-barrier logic to allow, block, or trigger gates based on vehicle status.

Q5: Is the PKC2641-Z28-P suitable for outdoor use in Australia?
A5: Absolutely. It features IP67 waterproofing, IK10 vandal protection, and operates reliably in –40 °C to +60 °C conditions, ideal for Australian outdoor environments.
