The ZKTeco MR1010 is a rugged, vandal-proof, and weather-resistant RFID reader designed for high-security outdoor access control applications. With an IK10 impact resistance rating and IP66 waterproof/dust-proof protection, the MR1010 ensures reliable operation even in harsh environments.
Operating at 13.56MHz, the MR1010 supports Mifare card credentials with a fast reading distance of 2–6cm. Its metal casing not only enhances durability but also delivers a sleek, professional appearance suitable for commercial, industrial, and government facilities.
The reader outputs Wiegand 26/34 bits for seamless integration with most standard access control panels, making it a dependable choice for both retrofit and new installations.
What’s in the Box
Main Features
-
Rugged & Secure Design – IK10 vandal-proof rating for impact resistance
-
Weatherproof Construction – IP66-rated for outdoor use in extreme conditions
-
Optimised RFID Performance – 13.56MHz operating frequency for secure card reading
-
Flexible Integration – Supports Wiegand 26/34-bit output for broad compatibility
-
Wide Temperature Range – Operates from -40°C to +60°C
Detailed Specifications
Specification |
Details |
Model |
MR1010 |
Frequency |
13.56MHz |
Card Type |
Mifare |
Reading Distance |
2–6cm |
Ingress Protection |
IP66 waterproof/dust-proof |
Impact Resistance |
IK10 vandal-proof |
Communication |
Wiegand 26 / 34 bits |
Operating Temp |
-40°C to +60°C |
Material |
Metal casing |
Mounting |
Wall mount, indoor/outdoor |
Warranty Information
3-Year Manufacturer Warranty – Covers manufacturing defects under normal operational conditions.
Excellence for the Australian and New Zealand Market
-
Designed to withstand ANZ’s harsh weather conditions
-
Distributed by authorised ZKTeco partners for genuine product assurance
-
Backed by local technical and warranty support
-
Compliant with ANZ access control integration standards
Datasheet & Resources
📄 Download ZKTeco MR1010 Datasheet
FAQs – ZKTeco MR1010
Q1: What is the operating frequency of the MR1010?
A1: The MR1010 operates at 13.56MHz for Mifare card reading.
Q2: Can the MR1010 be installed outdoors?
A2: Yes, it has an IP66 waterproof/dust-proof rating and operates from -40°C to +60°C.
Q3: Is the MR1010 vandal-proof?
A3: Yes, it carries an IK10 rating, offering high impact resistance.
Q4: What card types are supported?
A4: The MR1010 is compatible with Mifare RFID cards.
Q5: What output formats does it support?
A5: The reader supports Wiegand 26 and 34-bit output for integration with most access control panels.
