The EZIP EZ-IPC-T1B63-SMD 6MP IR fixed-focal eyeball network camera delivers detailed surveillance video, intelligent human and vehicle detection, 30-metre infrared night vision and flexible local or network recording. Featuring a wide-angle 2.8mm lens, built-in microphone, Smart H.265+ compression, 120dB WDR, PoE connectivity and an IP67-rated metal housing, it is designed for dependable residential, retail and commercial security installations.
Built around a 1/2.7-inch CMOS sensor, the EZ-IPC-T1B63-SMD records at up to 3072 × 2048 resolution at 20 frames per second and supports 2688 × 1520 at up to 25/30 fps. Its F1.6 aperture, day/night infrared-cut filter and integrated IR illuminator help maintain usable image detail in changing light conditions, including complete darkness with the illuminator active.
EZIP SMD Plus technology analyses motion events and classifies human and vehicle targets, helping reduce unnecessary alarms caused by irrelevant movement. Intelligent perimeter functions include intrusion and tripwire detection, while conventional event monitoring covers motion detection, video tampering, audio detection, storage errors, network disconnection, IP conflicts, illegal access and voltage abnormalities.
Smart H.265+ and Smart H.264+ encoding reduce bandwidth and storage requirements while maintaining useful video quality. Recording can be managed through a compatible network video recorder, NAS, FTP/SFTP server or a MicroSD card with a supported capacity of up to 256GB. The camera also supports ONVIF Profiles S, G and T for integration with compatible third-party surveillance platforms.
Power can be supplied through 12V DC or IEEE 802.3af PoE, allowing video, audio, data and power to travel over a single network cable when used with a compatible PoE switch or recorder. Its compact eyeball-style enclosure provides flexible pan, tilt and rotation adjustment and carries an IP67 ingress-protection rating for exposed indoor or outdoor installations.
Main Features
6MP maximum recording resolution of 3072 × 2048
1/2.7-inch progressive-scan CMOS image sensor
Wide-angle 2.8mm fixed-focal lens
F1.6 maximum aperture
Horizontal field of view of approximately 111°
SMD Plus human and vehicle classification
Intelligent intrusion and tripwire detection
Integrated infrared illumination up to 30 metres
Built-in microphone for audio capture
120dB Wide Dynamic Range
Smart H.265+ and Smart H.264+ video compression
Two configurable video streams
Up to 256GB MicroSD card support
12V DC or IEEE 802.3af PoE power
ONVIF Profiles S, G and T interoperability
IP67-rated weather-resistant enclosure
Metal inner core and metal outer cover
Operating temperature range from –40°C to +60°C
Compatible with SmartPSS Lite, DSS and DMSS
Mobile access through supported iOS and Android devices
Intelligent Video Functions
SMD Plus
Smart Motion Detection Plus classifies detected movement as a human or vehicle event. This helps filter motion alerts generated by less relevant activity and enables operators to focus on defined security targets.
Perimeter Protection
The camera supports intelligent intrusion and tripwire rules. Both functions can classify and accurately detect human and vehicle targets within configured surveillance areas.
Smart Search
When connected to a compatible Smart NVR, recorded intelligent events can be searched, extracted and grouped for more efficient incident review.
Abnormality Detection
Supported event and system alerts include:
Motion detection
Video tampering
Audio detection
No MicroSD card
MicroSD card full
MicroSD card error
Network disconnection
IP address conflict
Illegal access
Voltage detection
SMD events
Security exceptions
Tripwire and intrusion events
Image Enhancement
The EZ-IPC-T1B63-SMD includes multiple image-processing controls for difficult lighting and installation environments:
120dB Wide Dynamic Range
Backlight Compensation
Highlight Compensation
3D Noise Reduction
Automatic or manual gain control
Configurable white balance
Smart infrared illumination
Mirror mode
Four privacy-masking areas
Four rectangular motion-detection areas
Four Regions of Interest
0°, 90°, 180° and 270° image rotation
The 90° and 270° rotation modes are supported at 2688 × 1520 resolution and below.
What Is Included in the Box
1 × EZIP EZ-IPC-T1B63-SMD 6MP eyeball network camera
Detailed Specifications
Camera
Specification
Details
Image sensor
1/2.7-inch CMOS
Maximum resolution
3072 × 2048
Scanning system
Progressive scan
ROM
128MB
RAM
256MB
Electronic shutter
Automatic/manual, 1/3s to 1/100,000s
Minimum illumination, colour
0.007 lux at F1.6, 30 IRE
Minimum illumination, black and white
0.0007 lux at F1.6, 30 IRE
Minimum illumination with IR
0 lux
Signal-to-noise ratio
Greater than 56dB
IR distance
Up to 30m
IR control
Automatic or manual
Number of illuminators
1 infrared LED
Day/night mode
Auto ICR, colour or black and white
Lens and Viewing Angle
Specification
Details
Lens type
Fixed-focal
Lens mount
M12
Focal length
2.8mm
Maximum aperture
F1.6
Horizontal field of view
111°
Vertical field of view
58°
Diagonal field of view
132°
Iris control
Fixed
Minimum focus distance
1.1m
Pan adjustment
0° to 360°
Tilt adjustment
0° to 78°
Rotation adjustment
0° to 360°
DORI Distance
Detection Level
Approximate Distance
Detect
63.6m
Observe
25.4m
Recognise
12.7m
Identify
6.4m
DORI figures are calculated reference distances and should not be treated as guaranteed identification performance in every installation.
Video
Specification
Details
Video compression
H.265, H.264, H.264H, H.264B and MJPEG on sub-stream
Smart codec
Smart H.265+ and Smart H.264+
Main stream
3072 × 2048 at 1–20 fps
Alternative main stream
2688 × 1520 at 1–25/30 fps
Sub-stream
704 × 576 at 1–25 fps or 704 × 480 at 1–30 fps
Stream capability
2 streams
Bit-rate control
CBR or VBR
H.264 bit rate
32Kbps to 8192Kbps
H.265 bit rate
12Kbps to 8192Kbps
WDR
120dB
Noise reduction
3D NR
BLC/HLC
Supported
Privacy masking
4 areas
Region of Interest
4 areas
Motion detection
4 rectangular areas
Actual simultaneous frame rates may be limited by the camera’s total encoding capacity.
Supported Resolutions
3072 × 2048
2960 × 1668
2880 × 1620
2688 × 1520
2048 × 1536
2304 × 1296
1920 × 1080
1280 × 960
1280 × 720
704 × 576
704 × 480
640 × 480
352 × 288
352 × 240
Audio
Specification
Details
Built-in microphone
Yes
Audio compression
G.711a, G.711Mu, PCM and G.726
External audio input/output
Not specified
Artificial Intelligence
Function
Details
SMD Plus
Human and vehicle classification for motion events
Intrusion detection
Human and vehicle classification supported
Tripwire detection
Human and vehicle classification supported
Smart search
Available with a compatible Smart NVR
Network and Integration
Specification
Details
Network interface
RJ45, 10/100Base-T
Interoperability
ONVIF Profiles S, G and T; CGI
SDK and API
Supported
Maximum users/hosts
20
Total bandwidth
48Mbps
Local storage
MicroSD card up to 256GB
Network storage
FTP, SFTP and NAS
Management software
SmartPSS Lite and DSS
Mobile application
DMSS on supported iOS and Android devices
Browser support listed by manufacturer
Internet Explorer, Chrome and Firefox
Browser operation can vary with firmware version, browser version and whether a specific feature requires a plug-in.
The IP67 rating indicates protection against dust ingress and temporary immersion under the manufacturer’s specified test conditions. Correct cable sealing and installation are required to maintain the enclosure rating.
Accessory compatibility should be checked against the intended mounting surface and installation arrangement before ordering.
Practical Use Scenarios
Residential Perimeter Monitoring
Install the camera under an eave or on an exterior wall to monitor driveways, gates, side access points and entrances. Human and vehicle classification can help reduce alerts caused by irrelevant movement.
Retail Stores and Customer Areas
The wide 111° horizontal field of view is suitable for observing store entrances, counters, aisles and customer-access areas from a compact mounting position.
Warehouses and Loading Areas
Intrusion and tripwire rules can monitor defined access lanes, loading docks and restricted zones while distinguishing between human and vehicle targets.
Offices and Commercial Buildings
Use the built-in microphone and high-resolution image stream to monitor reception areas, corridors, building entries and shared facilities, subject to applicable audio-surveillance and privacy laws.
Car Parks and Driveways
SMD Plus vehicle classification, WDR and infrared illumination support monitoring of cars entering or moving through defined areas during the day or at night.
Schools and Community Facilities
The camera can monitor entrances, walkways and external building areas when installed and operated in accordance with local privacy, surveillance and child-safety requirements.
Installation Notes
A compatible PoE network video recorder or PoE switch can supply power and data through one Ethernet cable.
A separately regulated 12V DC power supply may also be used.
Use weatherproof cable termination and a compatible junction box for exposed installations.
A surveillance-grade MicroSD card is recommended for continuous or event-based edge recording.
Intelligent detection performance depends on mounting height, camera angle, target size, scene conditions and rule configuration.
Audio recording laws vary by jurisdiction. Confirm applicable privacy and surveillance requirements before enabling the microphone.
Installation by a suitably qualified security technician is recommended.
Warranty Information
2-year warranty
Brand Description
EZIP is a security-camera range focused on accessible network surveillance products with intelligent video functions. The range combines high-resolution imaging, efficient video compression and AI-assisted human and vehicle detection for residential and commercial security applications. The EZ-IPC-T1B63-SMD is also listed by Australian electrical and security distributors as an EZIP 6MP outdoor PoE camera.
Excellence for the Australian and New Zealand Market
The EZ-IPC-T1B63-SMD is suitable for a broad range of Australian and New Zealand residential and commercial surveillance environments, with an IP67-rated enclosure, a wide –40°C to +60°C operating range and flexible 12V DC or PoE installation.
The model is available through Australian electrical and electronic-security distribution channels, and the corresponding New Zealand product code has also appeared in New Zealand trade material.
For a reliable local installation:
Source the product through an authorised Australian or New Zealand supplier.
Confirm applicable electrical, cabling, privacy and surveillance requirements before installation.
Use compliant power supplies, network equipment and installation materials.
Confirm the seller’s warranty term and local return procedure before purchase.
Retain the invoice, serial number and installation records for warranty support.
Direct warranty enquiries through the supplying dealer or authorised brand representative.
Australian Standards, RCM registration, authorised-distributor status and direct manufacturer warranty handling should only be claimed where supporting documentation is available for the specific stock being supplied.
Frequently Asked Questions
What resolution does the EZ-IPC-T1B63-SMD security camera support?
The EZ-IPC-T1B63-SMD supports a maximum resolution of 3072 × 2048 at up to 20 fps. It can also record at 2688 × 1520 at up to 25 or 30 fps, depending on the configured video standard.
Does the EZ-IPC-T1B63-SMD identify humans and vehicles?
Yes. The EZ-IPC-T1B63-SMD features SMD Plus and intelligent perimeter protection, allowing supported motion, intrusion and tripwire events to classify human and vehicle targets.
How far can the EZ-IPC-T1B63-SMD see at night?
The integrated infrared illuminator in the EZ-IPC-T1B63-SMD has a specified maximum illumination distance of 30 metres. Actual night-time detail depends on the scene, reflective surfaces, weather and installation angle.
Does the EZ-IPC-T1B63-SMD have a built-in microphone?
Yes. The EZ-IPC-T1B63-SMD includes a built-in microphone and supports G.711a, G.711Mu, PCM and G.726 audio compression. Audio use must comply with applicable privacy and surveillance laws.
Can the EZ-IPC-T1B63-SMD be powered by PoE?
Yes. The EZ-IPC-T1B63-SMD supports IEEE 802.3af Power over Ethernet and can also operate from a suitable 12V DC power supply.
Is the EZ-IPC-T1B63-SMD suitable for outdoor installation?
The EZ-IPC-T1B63-SMD has an IP67-rated metal enclosure and an operating temperature range of –40°C to +60°C. Correct weatherproof installation, cable sealing and mounting are required to maintain protection.
Does the EZ-IPC-T1B63-SMD support MicroSD card recording?
Yes. The EZ-IPC-T1B63-SMD supports a MicroSD card with a capacity of up to 256GB. The memory card is optional unless expressly included by the seller.
Which lens is fitted to the EZ-IPC-T1B63-SMD?
The EZ-IPC-T1B63-SMD has a 2.8mm fixed-focal F1.6 lens with an approximate 111° horizontal, 58° vertical and 132° diagonal field of view.
Does the EZ-IPC-T1B63-SMD work with third-party NVRs?
The EZ-IPC-T1B63-SMD supports ONVIF Profiles S, G and T, which can assist integration with compatible third-party recorders. Specific functions, including AI event handling and audio, should be confirmed with the NVR manufacturer.
Which video compression formats does the EZ-IPC-T1B63-SMD support?
The EZ-IPC-T1B63-SMD supports H.265, H.264, H.264H and H.264B, plus MJPEG on the sub-stream. Smart H.265+ and Smart H.264+ are available to reduce storage and network-bandwidth requirements.
Does the EZ-IPC-T1B63-SMD support Wide Dynamic Range?
Yes. The EZ-IPC-T1B63-SMD supports 120dB WDR, helping preserve image detail in scenes containing bright highlights and darker shadowed areas.
Can the EZ-IPC-T1B63-SMD record without an NVR?
Yes. The EZ-IPC-T1B63-SMD can record to a supported MicroSD card and also supports FTP, SFTP and NAS storage configurations. An NVR remains useful for centralised recording, management and playback.
What mobile app works with the EZ-IPC-T1B63-SMD?
The EZ-IPC-T1B63-SMD is listed as compatible with DMSS on supported iOS and Android devices. Remote-access availability depends on correct network configuration and the current firmware and app versions.
What accessories are compatible with the EZ-IPC-T1B63-SMD?
Listed optional accessories for the EZ-IPC-T1B63-SMD include the PFA130-E junction box, PFB204W wall bracket, PFA152-E pole bracket, PFA106 adaptor and PFB220C ceiling bracket.
Is a power adaptor included with the EZ-IPC-T1B63-SMD?
A power adaptor is not confirmed as part of the standard package for the EZ-IPC-T1B63-SMD. The PFM321D 12V DC 1A adaptor is listed as an optional accessory, and the camera can alternatively be powered by a compatible PoE device.
What is the warranty period for the EZ-IPC-T1B63-SMD?
The manufacturer specifications supplied for the EZ-IPC-T1B63-SMD do not state a warranty duration. Buyers should refer to the warranty terms provided by the supplying retailer or authorised distributor.
Is the EZ-IPC-T1B63-SMD NDAA compliant?
NDAA compliance is not stated in the supplied documentation for the EZ-IPC-T1B63-SMD and should not be assumed. Obtain written confirmation from the supplier where NDAA compliance is a procurement requirement.
Is the EZ-IPC-T1B63-SMD NDSS approved?
No NDSS approval is stated for the EZ-IPC-T1B63-SMD. The NDSS relates to diabetes products and services in Australia and is not ordinarily applicable to network surveillance cameras.
Is the EZ-IPC-T1B63-SMD suitable for Australian and New Zealand security systems?
The EZ-IPC-T1B63-SMD is offered through Australian distribution channels and has also appeared in New Zealand trade material. Suitability for a particular project depends on local compliance requirements, system compatibility and installation conditions.
FREE SHIPPING ON ORDERS OVER $500 AUSTRALIA WIDE, except for large and heavy items such as cabinets, racks, Cable reels, and bollards, etc.
All orders are delivered using the Australia Post shipping method and this is the most efficient method of delivery.
A flat rate of $12 applies to all orders under $500, excluding heavy and large items, which will incur a specific shipping cost displayed at checkout.
Delivery typically takes 3-5 business days all over Australia, including Tasmania.
New Zealand: 10-15 business days.
Processing Times
We process orders from Monday to Friday, ensuring they are shipped within 24 hours of placement, excluding weekends and public holidays.
Tracking Your Order
Once your order is packed and dispatched from our warehouse, you will receive an email with a tracking number. This tracking number can be used to monitor your parcel's progress.
For your convenience, if you are not home at the time of delivery, the delivery driver will leave your parcel in a secure place if deemed safe. If it is not safe to leave the parcel, or if the parcel is too large, a card will be left with instructions on how to retrieve your parcel from the local depot.
Warranty period is given in the product description.
CCTV Tradie’s Products come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure of the Product and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the Products repaired or replaced if the Products fail to be of acceptable quality and the failure does not amount to a major failure.
✅ Change of mind returns: Accepted within 7 days of receiving your order.
✅ Products must be unused, uninstalled, and returned in their original packaging with all accessories.
✅ A completed Return Form must be included with every return.
✅ 7–30 Days: Approved change-of-mind returns are eligible for store credit only. A $30 restocking fee applies, depending on the value of the returned item.
❌ Used, installed, or damaged products are not eligible for return unless covered under warranty or Australian Consumer Law.
❌ Hard drives can only be returned if they have a confirmed major defect or failure.
🚚 Customers are responsible for return shipping costs unless the item has a major fault covered by Australian Consumer Law.
🔍 All returned items are inspected before any refund, replacement, or store credit is approved.
Neel and Panduka are friendly, helpful and knowledgeable. Fair prices and good range of products. Happy with my TP-Link VIGI camera system and PSS UPS battery.
Neelen was super helpful from start to finish and never tried to upsell me on things I didn’t need. Very fair pricing and honest advice. Would definitely recommend this shop. Thank you! ☺️
We respectfully acknowledge the Wurundjeri People, and their Elders past and present, who are the Traditional Owners of the land which we are located.
Supporting Local Business
By sourcing our products exclusively from local suppliers, we ensure quality, strengthen community ties, and contribute to the growth of our local economy.
Australian Standards
All products are authorized and compliant with Australian standards, ensuring top-tier security solutions that meet national quality requirements.
