The EZVIZ SD7 Smart Screen is a versatile and user-friendly device designed to centralize and simplify the management of your EZVIZ home security system. Featuring a sleek 7-inch IPS touchscreen, this smart screen allows you to effortlessly monitor and control various EZVIZ devices, including video doorphones, doorbells, peepholes, smart locks, and cameras. Its wireless design, powered by a 4,600 mAh rechargeable lithium battery, ensures flexible placement and easy installation without the need for complex wiring.

What's Included in the Box

• SD7 Smart Screen

• Type-C Charging Cable

• Wall Bracket

• Installation Sticker

• Double-sided Sticker

• Screw Kit

• Quick Start Guide

Main Features

• 7-Inch IPS Touchscreen: Provides clear and vibrant visuals with a resolution of 1024 × 600 pixels.

• Smart Integration: Seamlessly connects with up to 30 EZVIZ devices, allowing centralized control and monitoring.

• Rechargeable Battery: Equipped with a 4,600 mAh lithium battery supporting Type-C charging for extended use and convenience.

• Live View & Playback: Offers real-time monitoring and video playback capabilities.

• Two-Way Talk: Facilitates clear communication with visitors through its built-in high-sensitivity microphone and high-power speaker.

• 2.4 GHz Wi-Fi Connectivity: Ensures stable wireless connections for seamless operation.

• Flexible Installation: Supports wall-mounting, desk display, and portable use, adapting to various home settings.

Detailed Specifications

• Screen:

  • Size: 6.97 inches

  • Resolution: 1024 × 600

  • Type: IPS Full Screen

  • Touchscreen: Supported

• Battery:

  • Capacity: 4,600 mAh

• Interface:

  • Audio Input: Built-in high-sensitivity microphone

  • Audio Output: Built-in high-power speaker

  • Button: One-switch button

• Connectivity:

  • Maximum Access: Up to 30 EZVIZ devices (supports more devices with future OTA upgrades)

  • Supported Device Resolution: Up to 4K (playback supports up to 5MP)

  • Protocol: EZVIZ Cloud Proprietary Protocol

  • Wireless Standard: IEEE802.11b/g/n

  • Frequency Range: 2.4 GHz ~ 2.4835 GHz

  • Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

  • Transmission Rate: 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps

• General Specifications:

  • Operating Temperature: 0°C to 40°C

  • Operating Humidity: Less than 95% (no condensation)

  • Product Dimensions: 180.3 × 111.6 × 15.6 mm (7.10 × 4.39 × 0.61 inches)

• Certifications: CE / WEEE / RoHS / REACH

Warranty Information

The EZVIZ SD7 Smart Screen comes with a one-year warranty, ensuring peace of mind and reliable performance.

Brand Description

EZVIZ is a leading provider of smart home security solutions, dedicated to delivering innovative and reliable products that enhance the safety and convenience of homes worldwide. With a focus on user-friendly designs and cutting-edge technology, EZVIZ continues to set the standard in the smart home industry.

SKU

CS-SD7-R100-1WTC

Practical Use Scenarios

• Extended Home Coverage: Place the SD7 in various areas of your home, such as the bedroom or kitchen, to extend the communication range of your existing EZVIZ Video Doorphone systems. This setup allows you to answer doorbells and monitor entrances without rushing to a fixed monitor.

• Centralized Device Management: Use the SD7 as a central hub to manage and monitor up to 30 EZVIZ devices, including cameras, doorbells, and smart locks, providing a comprehensive view of your home's security status.

• Flexible Viewing Options: With its portable design, the SD7 can be wall-mounted, placed on a desk, or carried around the house, ensuring you have access to your security system wherever you are.

Datasheets or Downloadable Resources

For more detailed information and user manuals, please visit the official EZVIZ website.

Excellence for the Australian and New Zealand Market

The EZVIZ SD7 Smart Screen is designed to meet international quality standards, including CE, WEEE, RoHS, and REACH certifications. While specific Australian and New Zealand certifications are not mentioned, EZVIZ products are known for their high-quality manufacturing and compliance with global standards. For warranty services, customers can contact EZVIZ directly to ensure prompt and reliable support.

Frequently Asked Questions (FAQs)

1. Can the EZVIZ SD7 connect with non-EZVIZ security devices? No, the SD7 is specifically designed for EZVIZ devices and uses EZVIZ Cloud Proprietary Protocol for seamless integration.

2. How long does the battery last on a full charge? The 4,600 mAh rechargeable battery provides extended use, with exact duration depending on usage and settings.

3. Can I mount the SD7 on a wall? Yes, the SD7 supports both wall mounting and desk placement for flexible installation options.

4. Does the SD7 support 5GHz Wi-Fi? No, the SD7 only supports 2.4 GHz Wi-Fi for stable connectivity.

5. Is the SD7 compatible with the EZVIZ HP7 Video Doorphone? Yes, the SD7 works seamlessly with the HP7 Video Doorphone, extending its communication range within the home.

6. Can multiple SD7 devices be used in the same home? Yes, up to 10 SD7 devices can be interconnected for enhanced home security management.

7. What security encryption does the SD7 use? The SD7 supports 64/128-bit WEP, WPA/WPA2, and WPA-PSK/WPA2-PSK encryption to ensure secure communication.

8. What is included in the package when purchasing the SD7? The package includes the SD7 Smart Screen, Type-C charging cable, wall bracket, installation sticker, double-sided sticker, screw kit, and a quick start guide.

9. Can the SD7 be used outdoors? No, the SD7 is designed for indoor use only, with an operating temperature range of 0°C to 40°C.

10. How can I update the firmware on my SD7? Firmware updates can be installed via the EZVIZ app, ensuring your device stays up to date with the latest features and security improvements.
