Upgrade your site’s security with the HiLook IPC‑T363H‑MU 6 MP network turret camera — delivering ultra‑clear imaging, intelligent human/vehicle detection, smart hybrid lighting for true color event capture, built‑in audio, and rugged IP67 weather resistance. Perfect for homes, businesses, and commercial facilities.
Product Description
The HiLook IPC‑T363H‑MU is a 6 MP intelligent turret network camera designed to capture high‑resolution video with advanced analytics and durability for both indoor and outdoor use. Featuring Human & Vehicle Intelligent Detection, this camera enhances situational awareness and reduces false alarms. Its Smart Hybrid Light ensures color imaging during critical events, while the built‑in microphone enables real‑time audio monitoring. Combined with efficient H.265+ compression, this camera provides exceptional quality and storage efficiency for modern security systems.
Ideal for residential properties, retail stores, office buildings, and warehouses, the IPC‑T363H‑MU delivers a reliable and robust surveillance solution.
What’s Included in the Box
✔ 1 × HiLook IPC‑T363H‑MU 6 MP Network Camera
✔ Quick Installation Guide
✔ Mounting Accessories Kit
✔ Warranty Card
Main Features
-
6 MP High‑Quality Imaging: Ultra‑clear 3200 × 1800 resolution for detailed video.
-
Intelligent Detection: Supports Human & Vehicle Detection to minimize false alarms.
-
Smart Hybrid Light: Ensures color images when events occur, even in low light.
-
Built‑In Microphone: Real‑time audio monitoring for enhanced situational awareness.
-
Robust Weatherproof Design: IP67‑rated protection against dust and water for outdoor use.
-
Efficient Video Compression: Advanced H.265+ technology reduces bandwidth and storage use.
-
Flexible Field of View Options: 2.8 mm or 4 mm lenses for wide or focused coverage.
Detailed Specifications
Camera & Optics
| Spec |
Details |
| Image Sensor |
1/2.4″ Progressive Scan CMOS |
| Resolution |
Up to 3200 × 1800 (6 MP) |
| Min. Illumination |
Color: 0.001 Lux @ (F1.2, AGC ON) / B/W: 0 Lux with IR |
| Lens Options |
2.8 mm or 4 mm Fixed Lens |
| FOV (2.8 mm) |
H: 119.6°, V: 60°, D: 149° |
| FOV (4 mm) |
H: 96.8°, V: 50°, D: 115° |
| IR & White Light Range |
Up to 30 m |
| Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–75°, Rotate: 0°–360° |
Video & Compression
| Feature |
Supported |
| Frame Rate |
Up to 20 fps @ all resolutions (incl. 6 MP) |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Bit Rate |
32 Kbps–16 Mbps |
| ROI |
1 fixed region for main stream |
Audio
Network & Security
-
Simultaneous Live View: Up to 6 channels
-
Protocols: TCP/IP, DHCP, DNS, HTTP, RTSP, NTP, FTP & more
-
Security: Password protection, authentication, HTTPS & audit logs
-
ONVIF & API Support: Yes (Profile S, T, G, ISAPI, SDK)
Smart Events & Analytics
-
Basic: Motion detection, tampering alarm
-
Smart: Line crossing, intrusion detection with human/vehicle trigger support
-
Linkage Actions: FTP upload, email alert, capture trigger
Environmental
-
Operating Temp: −30 °C to 60 °C
-
Humidity: ≤ 95% (non‑condensing)
-
Protection: IP67 – Weather & Dust Resistant
-
Weight (with package): ~909 g
-
Dimensions: Ø127.3 mm × 95.9 mm
Installation & Mounting
Compatible with a range of mounting accessories (optional, sold separately):
-
DS‑1271ZJ‑130‑TRL – Pendant mount
-
DS‑1276ZJ‑SUS – Corner mount (Black)
-
DS‑1281ZJ‑M – Inclined ceiling mount
-
DS‑1275ZJ‑SUS – Vertical pole mount
-
DS‑1273ZJ‑130B‑TRL – Wall mount (Black)
-
DS‑1280ZJ‑DM8 – Junction box
These options provide flexible installation for walls, ceilings, corners, poles, and pendants to suit every environment.
Warranty Information
This HiLook IPC‑T363H‑MU camera includes a 3 year standard manufacturer‑backed warranty that supports product quality and performance assurance. Warranty claims and service are handled via authorized resellers or the brand directly, ensuring dependable support throughout the coverage period.
Datasheets
Brand Overview – HiLook (By Hikvision)
HiLook is Hikvision’s value‑oriented brand combining reliable performance with cost‑effective pricing. Designed for homes, SMBs, retail spaces, and commercial facilities, HiLook products deliver intuitive features, advanced analytics, and robust durability backed by industry‑leading support and global quality standards.
Excellence for the Australian & New Zealand Market
The IPC‑T363H‑MU is engineered for optimal performance in Australian and New Zealand conditions, conforming to regional safety and EMC standards (e.g., RCM compliance). Built‑in weatherproofing and rugged design make it suitable for diverse climates — from urban centres to outdoor perimeters. Warranty support and service are provided through authorized channels, giving buyers peace of mind and compliance with local quality expectations.
FAQs – IPC‑T363H‑MU
Q1: What resolution does the HiLook IPC‑T363H‑MU camera support?
A1: The IPC‑T363H‑MU supports up to 6 MP (3200 × 1800) resolution for high‑quality imaging.
Q2: Does the IPC‑T363H‑MU support intelligent detection?
A2: Yes — the IPC‑T363H‑MU supports Human and Vehicle Intelligent Detection to reduce false alarms.
Q3: What environmental rating does the IPC‑T363H‑MU have for outdoor use?
A3: The IPC‑T363H‑MU is IP67 rated, making it suitable for outdoor installation and resistant to dust and water.
Q4: Can the IPC‑T363H‑MU record audio?
A4: Yes — the IPC‑T363H‑MU includes a built‑in microphone for real‑time audio monitoring.
Q5: What mounting options are available for the IPC‑T363H‑MU?
A5: The IPC‑T363H‑MU supports accessories like pendant, corner, pole, wall, and ceiling mounts to suit varied installation environments.
