The HR9-12 (Part Number: TB100120), also known as HR9-12FR (flame-retardant version), is a 12V 9Ah high-rate sealed lead acid (SLA) battery specifically designed for UPS systems, power packs, and other high-discharge applications. Built with AGM (Absorbent Glass Mat) VRLA technology, this battery provides maintenance-free performance, excellent power density, and dependable operation even under demanding load conditions.
Certified to ISO 9001, ISO 14001, UL, and CE, the HR9-12 meets or exceeds IEC61056, JIS C8702, and GB/T 19639 standards. It features Faston Tab T2 (250) terminals for quick connections, and its compact design fits most UPS housings. With a max discharge current of 120A (5 sec), the HR9-12 outperforms standard 9Ah batteries in critical backup applications.
What’s Included in the Box
-
1 x HR9-12 (or HR9-12FR) 12V 9Ah Sealed Lead Acid Battery
-
Factory-sealed unit with Faston T2 terminal (F1 and B0 optional)
-
Packaged for safe transport and storage
Main Features
-
✅ High-Rate Discharge Design – Delivers up to 120A (5 seconds)
-
✅ Optimized for UPS & Emergency Systems – Reliable for sudden backup needs
-
✅ Faston Tab T2 Terminals – Secure and easy to connect
-
✅ Flame-Retardant Version Available (HR9-12FR) – Enhanced safety
-
✅ Low Self-Discharge – Less than 3% capacity loss per month at 25°C
-
✅ Non-Spillable, Maintenance-Free – Safe for indoor and enclosed applications
-
✅ Compatible with Multiple Applications – Toy cars, medical gear, field testing devices
Detailed Specifications
| Attribute |
Value |
| Part Number |
TB100120 / HR9-12 / HR9-12FR |
| Battery Type |
AGM Sealed Lead Acid (VRLA) |
| Nominal Voltage |
12V |
| Rated Capacity |
9Ah @ 20hr-rate to 1.75V/cell at 25°C |
| Weight |
Approx. 2.7 kg |
| Max Discharge Current |
120A (5 seconds) |
| Self-Discharge Rate |
<3% per month at 25°C |
| Float Charge Voltage |
13.7–13.9 VDC/unit at 25°C |
| Cycle Charge Voltage |
14.6–14.8 VDC/unit at 25°C |
| Max Charging Current |
2.7A (approx.) |
| Operating Temp. Range |
Discharge: -20°C to 60°C / Charge: 0°C to 50°C |
| Storage Temp. Range |
-20°C to 60°C |
| Terminals |
Faston T2 (250) standard; T1 & B0 optional |
| Certifications |
ISO 9001, ISO 14001, UL, CE |
| Dimensions (mm) |
151 (L) × 65 (W) × 100 (H) |
Warranty Information
This battery is covered by a 12-month manufacturer’s warranty against defects in materials and workmanship when used under recommended conditions. Battery life is extended with proper storage and float/cycle charging.
Brand Description
B.B. Battery, a globally recognized energy solutions provider, designs high-performance sealed lead acid batteries that power mission-critical systems in UPS, medical, telecom, and industrial environments. The HR Series is built for high-rate discharge and long-term reliability.
SKU
TB100120 / HR9-12 / HR9-12FR
Practical Use Scenarios
-
⚡ UPS Systems – Quick-response backup during power interruptions
-
🧰 Testing & Lab Equipment – Stable power for field and lab instruments
-
🎮 Electric Toy Vehicles – High burst power for motor-driven toys
-
💡 Emergency Lighting – High-capacity, quick-recharge backup cells
-
🛠️ Mobile Power Packs – Ideal for custom energy storage builds
Datasheets or Downloadable Resources
Excellence for the Australian and New Zealand Market
-
✔️ Meets Global Standards (IEC, JIS, GB/T)
-
✔️ Local Distribution Support for ANZ Region
-
✔️ Performance Optimized for Temperature Extremes in AU/NZ
-
✔️ Warranty & Technical Support Available Locally
-
✔️ Certified for Use in Professional UPS & Safety Systems
FAQs – Product Code: TB100120 / HR9-12
Q1: What is the rated capacity of the HR9-12 battery?
A1: The battery delivers 9Ah at 20-hour discharge rate to 1.75V/cell at 25°C.
Q2: Is the HR9-12 battery suitable for high-discharge devices like UPS?
A2: Yes, it’s engineered for high-rate discharge, with a maximum of 120A for 5 seconds.
Q3: Does the HR9-12 battery require maintenance?
A3: No, it uses sealed AGM technology, making it completely maintenance-free.
Q4: What terminal types are available for the HR9-12?
A4: It comes standard with T2 (Faston 250) terminals. T1 and B0 are available upon request.
Q5: Is the HR9-12 battery approved for use in Australia and New Zealand?
A5: Yes, it is ISO, UL, and CE certified, and suitable for professional and residential systems in the ANZ market.
