The KONEC KMQ-ZG-2001-RF Zigbee Garage Door Controller is a compact smart access-control module designed to integrate compatible garage door motors into the KONEC smart-home ecosystem. Featuring two relay outputs rated up to 10A each, flexible 7–32V AC/DC or 5V USB power, Zigbee connectivity and app-based control, this discreet 116 × 38 × 25mm controller provides a practical way to add connected garage access to compatible installations.
Designed for discreet connection to a compatible garage motor, the KMQ-ZG-2001-RF allows the garage door to be controlled through the Arks by Konec Solutions app and compatible KONEC control panels. A KONEC Zigbee hub/gateway is required for setup and operation.
Beyond straightforward remote garage control, the controller supports smart scene control, allowing garage-door actions to form part of broader automation scenarios involving compatible smart-home devices. Published KONEC information describes applications involving connected lighting, curtains, air conditioning and other smart devices.
The controller also supports OTA firmware updates, enabling firmware notifications and updates through the associated app. Its broad 7–32V AC/DC input range, alternative USB 5V supply option and compact PC enclosure provide installation flexibility for compatible garage-door systems.
Important: The KMQ-ZG-2001-RF requires a compatible KONEC Zigbee hub/gateway to be set up and function within the connected smart-home ecosystem.
Main Features
-
Zigbee wireless garage door controller
-
Designed for integration with compatible garage door motors
-
2-channel relay output
-
10A maximum current
-
Flexible 7–32V AC/DC input
-
Alternative 5V USB power
-
Compact 116 × 38 × 25mm design
-
Remote garage access control through the Arks by Konec Solutions app
-
Compatible KONEC control-panel operation
-
Smart scene-control functionality
-
Can trigger compatible smart-home automation scenarios
-
OTA firmware update support
-
Network pairing LED indication
-
Wide -20°C to +70°C operating temperature range
-
Requires a compatible KONEC Zigbee hub/gateway
-
Suitable for new smart-home projects and compatible retrofit applications
Detailed Specifications
| Specification |
Details |
| Brand |
KONEC |
| Model / Part Number |
KMQ-ZG-2001-RF |
| KONEC SKU |
KSL00226 |
| Product Type |
Zigbee Garage Door Controller |
| Wireless Protocol |
Zigbee |
| Channels |
2-Channel Output |
| Relay Outputs |
2 |
| Maximum Current |
10A |
| Input Voltage |
AC/DC 7–32V |
| USB Power |
5V |
| Housing Material |
PC |
| Operating Temperature |
-20°C to +70°C |
| Operating Humidity |
10%–90% RH, Non-Condensing |
| Dimensions |
116 × 38 × 25mm |
| App Control |
Supported via KONEC smart-home ecosystem |
| App |
Arks by Konec Solutions |
| Control Panel Integration |
Supported |
| Scene Control |
Supported |
| OTA Updates |
Supported |
| Network Pairing Indicator |
LED flashes twice per second in network pairing mode |
| Zigbee Hub/Gateway Required |
Yes |
Published specifications identify the controller as a Zigbee, two-channel device with 7–32V AC/DC or USB 5V power, 10A maximum current and dimensions of 116 × 38 × 25mm.
What's Included in the Box
Smart Control & Automation
The KMQ-ZG-2001-RF is designed to provide connected control of a compatible garage motor rather than functioning as a standalone garage-door opener.
Once incorporated into a compatible KONEC Zigbee system, users can control the garage motor through the Arks application or a compatible KONEC control panel. Scene control allows garage-door operation to interact with other compatible smart-home devices.
For example, a suitable automation configuration could coordinate garage access with compatible connected devices such as lighting or other home-automation equipment. The exact automation possibilities depend on the connected KONEC system and configuration.
Practical Use Scenarios
Smart Residential Garages: Add Zigbee connectivity to a compatible garage motor so garage access can become part of a wider KONEC smart-home system.
Garage Door Retrofit Projects: The compact 116 × 38 × 25mm controller can be discreetly incorporated into suitable existing garage-door installations where electrical and control compatibility has been confirmed.
New Smart Homes: Integrate garage access alongside other compatible KONEC access, lighting, climate and automation products within a connected residential project.
Scene-Based Automation: Use garage-door activity as part of configured smart-home scenes involving compatible devices such as lighting, curtains or air conditioning.
Control Panel Integration: Operate the compatible garage motor through supported KONEC control panels as part of a centralised smart-home interface.
Gateway Requirement
The KONEC KMQ-ZG-2001-RF requires a KONEC Zigbee hub/gateway to be set up and function as a connected Zigbee device. The gateway provides the link required for integration with the wider KONEC smart-home ecosystem.
Customers should ensure that a compatible KONEC Zigbee gateway is already installed or purchased separately where required.
Installation Considerations
Compatibility between the KMQ-ZG-2001-RF and the intended garage-door motor/control circuitry should be confirmed before installation.
Electrical connection, relay configuration and power-supply selection must follow the supplied KONEC installation documentation and applicable local electrical requirements. Where electrical work requires a licensed professional under local regulations, installation should be performed accordingly.
Warranty Information
1 year Warranty
About KONEC
KONEC Australia develops integrated smart-home solutions across access control, centralised management, networking, lighting, switches, climate control and security. The Australia-based company works across residential and commercial smart-building projects and provides connected products designed to operate within a broader smart-home ecosystem.
Datasheets & Downloadable Resources
Product Datasheet:
Download KMQ-ZG-2001-RF Datasheet
Installation Manual:
Download KMQ-ZG-2001-RF Installation Manual
Excellence for the Australian and New Zealand Market
The KONEC KMQ-ZG-2001-RF Zigbee Garage Door Controller is part of KONEC's Australian smart-home product ecosystem, which is designed around integrated access, automation, lighting, climate and security solutions for residential and commercial projects. KONEC describes itself as Australia-based and specifically focused on the requirements of local residential and commercial projects.
Its flexible 7–32V AC/DC or USB 5V power options, compact dimensions, Zigbee connectivity and broad operating-temperature range make the controller adaptable to a variety of compatible smart-garage installations.
KONEC also publishes ongoing cybersecurity information for its connected products and states that products it supplies will receive security updates until at least the end of 2027, subject to its published security-update policy.
Any project-specific Australian or New Zealand electrical, building, garage-door or automation requirements should be checked before installation. No NDSS approval or other unrelated certification is claimed for KMQ-ZG-2001-RF unless specifically documented for this model.
FAQs
What is the KONEC KMQ-ZG-2001-RF Zigbee Garage Door Controller?
The KONEC KMQ-ZG-2001-RF is a compact Zigbee controller designed to connect with compatible garage motors, enabling garage access to integrate with the KONEC smart-home ecosystem.
Does the KONEC KMQ-ZG-2001-RF require a Zigbee gateway?
Yes. The KONEC KMQ-ZG-2001-RF requires a compatible KONEC Zigbee hub/gateway to be set up and operate as part of the connected KONEC ecosystem.
Can the KONEC KMQ-ZG-2001-RF control a garage door from an app?
Yes. The KONEC KMQ-ZG-2001-RF supports control through the Arks by Konec Solutions app when correctly installed, paired and connected through the required KONEC Zigbee system.
How many relay outputs does the KONEC KMQ-ZG-2001-RF have?
The KONEC KMQ-ZG-2001-RF is a two-channel controller with two relay outputs, with the supplied product information specifying 10A for each relay.
What input voltage does the KONEC KMQ-ZG-2001-RF support?
The KONEC KMQ-ZG-2001-RF supports 7–32V AC/DC input and can alternatively be powered using 5V USB.
What are the dimensions of the KONEC KMQ-ZG-2001-RF?
The KONEC KMQ-ZG-2001-RF measures approximately 116mm × 38mm × 25mm, providing a compact form factor for discreet installation.
What is the operating temperature of the KONEC KMQ-ZG-2001-RF?
The KONEC KMQ-ZG-2001-RF has a published operating-temperature range of -20°C to +70°C.
Does the KONEC KMQ-ZG-2001-RF support smart-home scenes?
Yes. The KONEC KMQ-ZG-2001-RF supports scene control within a compatible KONEC smart-home configuration, allowing garage operation to interact with other compatible smart devices.
Does the KONEC KMQ-ZG-2001-RF support firmware updates?
Yes. The KONEC KMQ-ZG-2001-RF supports OTA updates, with firmware notifications and updating available through the associated smart-home app.
Can the KONEC KMQ-ZG-2001-RF work with a KONEC control panel?
Yes. Published product information states that a compatible garage motor connected through the KONEC KMQ-ZG-2001-RF can be controlled through the application and KONEC control panel.
Is the KONEC KMQ-ZG-2001-RF suitable for retrofitting an existing garage door?
The compact KONEC KMQ-ZG-2001-RF may be suitable for compatible retrofit applications, but compatibility with the existing garage motor, control terminals, power supply and electrical configuration must be confirmed before installation.
What wireless technology does the KONEC KMQ-ZG-2001-RF use?
The KONEC KMQ-ZG-2001-RF uses the Zigbee wireless protocol to communicate within a compatible KONEC smart-home system.
What is the KONEC SKU for the KMQ-ZG-2001-RF?
The published KONEC SKU for the KONEC KMQ-ZG-2001-RF Zigbee Garage Door Controller is KSL00226.
Can the KONEC KMQ-ZG-2001-RF trigger other smart devices?
The KONEC KMQ-ZG-2001-RF supports scene-based automation within a compatible KONEC installation. Published product information describes integration scenarios involving devices such as lighting, curtains and air conditioning.
Is professional installation recommended for the KONEC KMQ-ZG-2001-RF?
Installation of the KONEC KMQ-ZG-2001-RF should follow the manufacturer's installation manual and applicable local electrical requirements. Compatibility with the garage motor and its control circuitry should be confirmed before connection.
