The Hikvision DS-PM2-S(AU) 3G/4G Communication Module is a compact mobile communications module designed for compatible Hikvision AX Hybrid Pro alarm control panels. Supporting FDD-LTE 4G and dual-band UMTS/HSDPA/HSPA+ 3G connectivity, the DS-PM2-S(AU) provides a cellular communication option for compatible Hikvision intrusion alarm installations.
Designed specifically as a communication module for the AX Hybrid Pro series, the DS-PM2-S(AU) supports FDD-LTE Bands B1/B3/B5/B7/B8/B28 and UMTS/HSDPA/HSPA+ Bands B1/B5. Hikvision's AX Hybrid Pro platform supports multiple communication methods, including LAN, Wi-Fi, PSTN, GPRS and 3G/4G, depending on system configuration and installed hardware.
With a compact footprint of 62.03 × 88.28 mm and a weight of just 28 g, the module installs within the appropriate communication-module position of a compatible AX Hybrid Pro panel. It features a single SIM slot and is specified for operation from -10°C to +40°C.
The DS-PM2-S(AU) is particularly suited to professional security installations requiring cellular connectivity as part of an AX Hybrid Pro alarm system.
Main Features
-
Genuine Hikvision 3G/4G communication module
-
Product model: DS-PM2-S(AU)
-
Designed for compatible Hikvision AX Hybrid Pro series control panels
-
Supports FDD-LTE 4G
-
FDD-LTE frequency bands: B1, B3, B5, B7, B8 and B28
-
Supports dual-band UMTS/HSDPA/HSPA+
-
UMTS/HSDPA/HSPA+ bands: B1 and B5
-
1 × SIM slot
-
Supports 3G/4G reporting
-
Compact internal module design
-
Lightweight 28 g construction
-
Operating temperature range of -10°C to +40°C
Detailed Specifications
| Specification |
Details |
| Brand |
Hikvision |
| Model / Product Code |
DS-PM2-S(AU) |
| Product Type |
3G/4G Communication Module |
| Compatible Series |
Hikvision AX Hybrid Pro |
| SIM Slot |
1 |
| 4G Standard |
FDD-LTE |
| FDD-LTE Bands |
B1 / B3 / B5 / B7 / B8 / B28 |
| 3G Standard |
Dual-Band UMTS / HSDPA / HSPA+ |
| 3G Bands |
B1 / B5 |
| Report Method |
3G/4G supported |
| Dimensions (W × H × D) |
62.03 × 88.28 mm |
| Weight |
28 g |
| Operating Temperature |
-10°C to +40°C |
| Installation Type |
Internal communication module for compatible control panel |
What's Included in the Box
Any additional accessories, SIM card, control panel, cabling or installation equipment are not included and should not be assumed to form part of the package.
Compatibility
The DS-PM2-S(AU) is specified by Hikvision as a 3G/4G communication module for the AX Hybrid Pro series. Hikvision's AX Hybrid Pro documentation identifies the DS-PM2-S(AU) as the 3G/4G communication-module option within the product family.
Compatibility should always be confirmed against the exact AX Hybrid Pro control-panel model, hardware revision and current Hikvision documentation before purchase or installation.
Practical Use Scenarios
Residential Alarm Systems: Add supported cellular communication to a compatible Hikvision AX Hybrid Pro security system installed in a house, apartment or other residential property.
Commercial Security Installations: Suitable for compatible AX Hybrid Pro installations in offices, shops and other commercial premises where 3G/4G connectivity forms part of the alarm-system design.
Multi-Path Communication Designs: AX Hybrid Pro supports multiple communication methods depending on panel configuration, making the DS-PM2-S(AU) useful where cellular communication is required alongside other available network options.
Professional Security Upgrades: Suitable when adding the supported 3G/4G communication capability to an appropriately configured AX Hybrid Pro control panel.
Warranty Information
2 year Warranty
About Hikvision
Hikvision is a global manufacturer of security and AIoT products and solutions, with product ranges covering video security, intrusion alarms, access control, intercom and related security technologies. The AX Hybrid Pro family combines wired and wireless security capabilities and supports multiple communication methods for professional intrusion-alarm applications.
SKU
DS-PM2-S(AU)
Datasheets & Downloadable Resources
For technical installation, always refer to the latest documentation provided by Hikvision for the control panel and communication module.
Excellence for the Australian and New Zealand Market
The DS-PM2-S(AU) is the AU-designated version of Hikvision's AX Hybrid Pro 3G/4G communication module and supports FDD-LTE Band 28 alongside B1/B3/B5/B7/B8. Hikvision Australia & New Zealand documentation lists the DS-PM2-S(AU) as a 3G/4G communication module within the AX Hybrid Pro product family.
For Australian and New Zealand installations, cellular carrier compatibility, network availability, panel compatibility and any installation or regulatory requirements should be verified for the specific project before deployment.
No claim of NDSS approval is made for this product, as NDSS approval is not relevant to this type of security communication module. Likewise, specific Australian certification or compliance claims should only be made where supported by current certification documentation for this exact model.
Frequently Asked Questions
What is the Hikvision DS-PM2-S(AU) used for?
The Hikvision DS-PM2-S(AU) is a 3G/4G communication module designed for compatible Hikvision AX Hybrid Pro series alarm control panels, providing supported cellular communication capability.
Which 4G bands does the Hikvision DS-PM2-S(AU) support?
The Hikvision DS-PM2-S(AU) supports FDD-LTE Bands B1, B3, B5, B7, B8 and B28.
Does the Hikvision DS-PM2-S(AU) support 3G networks?
Yes. The DS-PM2-S(AU) supports dual-band UMTS/HSDPA/HSPA+ on Bands B1 and B5.
Is the Hikvision DS-PM2-S(AU) compatible with AX Hybrid Pro alarm panels?
The DS-PM2-S(AU) is specifically identified by Hikvision as a 3G/4G communication module for the AX Hybrid Pro series. Exact panel and hardware compatibility should be checked before installation.
Does the Hikvision DS-PM2-S(AU) have a SIM card slot?
Yes. The DS-PM2-S(AU) specification lists one SIM slot.
What are the dimensions of the Hikvision DS-PM2-S(AU)?
The DS-PM2-S(AU) measures 62.03 mm × 88.28 mm according to Hikvision's specification.
How much does the Hikvision DS-PM2-S(AU) weigh?
The DS-PM2-S(AU) weighs approximately 28 g.
What is the operating temperature of the Hikvision DS-PM2-S(AU)?
The DS-PM2-S(AU) has a specified operating temperature range of -10°C to +40°C.
Does the Hikvision DS-PM2-S(AU) support LTE Band 28?
Yes. DS-PM2-S(AU) supports FDD-LTE Band 28, along with Bands B1, B3, B5, B7 and B8.
Is a SIM card included with the Hikvision DS-PM2-S(AU)?
The supplied Hikvision specification does not state that a SIM card is included with the DS-PM2-S(AU). A suitable SIM and cellular service should therefore be sourced separately where required.
Where can I find the Hikvision DS-PM2-S(AU) datasheet?
The official DS-PM2-S(AU) datasheet is available through Hikvision's product documentation resources and contains the module's supported cellular bands, dimensions, weight and operating-temperature specifications.
