Upgrade your business network with the TP-Link EAP110, a cost-effective yet powerful 300Mbps Wireless N Ceiling Mount Access Point designed for easy deployment and robust performance. Ideal for small businesses, offices, schools, hospitality venues, and retail environments, this access point provides solid wireless coverage, enterprise security features, and centralized management through TP-Link’s Omada platform.
The EAP110 delivers up to 300 Mbps wireless speeds over the 2.4GHz band using 2×2 MIMO technology, ensuring stable connections for simultaneous users. With support for over 100 concurrent clients and up to 60㎡ (650 ft²) of coverage, it’s a reliable choice for high-density environments.
Integrated into the Omada SDN solution, the EAP110 allows for centralized management of hundreds of access points via the Omada app, web interface, or Omada controllers (OC300, OC200, or software controller). Administrators benefit from Zero-Touch Provisioning, streamlined deployment, and advanced monitoring and configuration capabilities.
The EAP110’s passive PoE support simplifies installation, delivering both data and power through a single Ethernet cable up to 100 meters, perfect for ceiling or wall mounting where power outlets are scarce. The sleek design and included mounting kits make it easy to blend into any interior space.
Security is enterprise-class, featuring WPA/WPA2-Enterprise, 802.1X, rogue AP detection, SSID to VLAN mapping, and a captive portal for secure guest access and user authentication.
From small office Wi-Fi to hospitality guest networks, the EAP110 combines affordability, reliability, and professional-grade features for seamless wireless connectivity.
What’s Included in the Box
TP-Link EAP110 300Mbps Wireless N Ceiling Mount Access Point
Passive PoE Adapter
Power Cord
Mounting Kits
Resource CD
Installation Guide
Main Features
300Mbps Wireless N Speed: Delivers up to 300 Mbps on the 2.4GHz band for stable, fast connectivity.
Omada Controller Integration: Centralized management for scalable networks through Omada Hardware Controllers, Software Controller, or Omada Cloud.
Passive PoE Support: Simplifies installation with power and data over a single Ethernet cable up to 100 meters.
Captive Portal Authentication: Provides secure, customizable guest access for businesses.
Multi-SSID Support: Up to 8 SSIDs for network segmentation, allowing different access policies for various user groups.
Enterprise-Class Security: Includes WPA/WPA2-Enterprise, rogue AP detection, MAC filtering, VLAN mapping, and more.
Sleek Ceiling Mount Design: Blends into modern interiors while providing reliable wireless coverage.
Flexible Management: Omada app, SNMP, SSH, web interface, and multi-site management support.
Detailed Specifications
Category
Details
Wireless Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency Band
2.4 - 2.4835 GHz
Max Speed
Up to 300 Mbps
MIMO Technology
2×2 MIMO
Signal Rates
11n: Up to 300 Mbps 11g: Up to 54 Mbps 11b: Up to 11 Mbps
Reception Sensitivity
300M: -71 dBm @10% PER 150M: -75 dBm @10% PER 54M: -78 dBm @10% PER 11M: -93 dBm @8% PER
Antenna Type
2 internal omni antennas, 3 dBi each
Transmission Power
CE: <20 dBm FCC: <26 dBm
Ethernet Port
1 × Fast Ethernet (RJ-45) supporting Passive PoE
Power Consumption
Max. 7.7W
PoE Support
24VDC / 1A Passive PoE
Coverage
Up to 60㎡ (650 ft²)
Concurrent Clients
100+
Wireless Functions
Multiple SSIDs (up to 8), Automatic Channel Assignment, Transmit Power Control, QoS (WMM), Rate Limiting, Wireless Schedule, Wireless Statistics
Wireless Security
Captive Portal, WPA/WPA2-Enterprise, 802.1X, MAC Filtering, Rogue AP Detection, SSID to VLAN Mapping, Wireless Isolation
TP-Link provides a limited warranty covering defects in materials and workmanship for the EAP110. Warranty terms vary by region. Customers in Australia and New Zealand benefit from local support via authorized partners for reliable service and warranty assistance.
Brand Description
TP-Link is a leading global provider of networking solutions, renowned for delivering high-quality, innovative products to businesses and consumers worldwide. TP-Link empowers organizations with reliable, scalable networking solutions designed for performance, security, and simplicity.
SKU
EAP110
Practical Use Scenarios
✅ Perfect for small offices seeking reliable, affordable ceiling-mounted Wi-Fi coverage.
✅ Ideal for hospitality venues offering secure guest access via captive portal authentication.
✅ Excellent for retail shops needing simple, managed wireless networks with multiple SSIDs for staff and customers.
✅ Suitable for educational institutions deploying cost-effective Wi-Fi across classrooms and common areas.
Excellence for the Australian and New Zealand Market
The TP-Link EAP110 complies with Australian and New Zealand standards for quality and safety, ensuring dependable performance in diverse commercial environments. All TP-Link products sold in ANZ are sourced through authorized distribution channels, guaranteeing genuine products, regulatory compliance, and comprehensive local support.
Businesses across Australia and New Zealand can confidently deploy the EAP110, backed by TP-Link’s industry-leading expertise and commitment to reliable connectivity.
FAQs
Q1: What is the maximum wireless speed of the TP-Link EAP110 (SKU: EAP110)? A1: The EAP110 offers wireless speeds up to 300 Mbps on the 2.4GHz band.
Q2: Does the TP-Link EAP110 (SKU: EAP110) support centralized management? A2: Yes! The EAP110 integrates with the Omada platform for centralized management via hardware controllers, software controller, or the Omada Cloud.
Q3: How many SSIDs can the TP-Link EAP110 (SKU: EAP110) support? A3: The EAP110 supports up to 8 SSIDs for network segmentation and flexible access policies.
Q4: Does the TP-Link EAP110 (SKU: EAP110) support PoE? A4: Absolutely. The EAP110 supports 24V Passive PoE, simplifying installation where power outlets are limited.
Q5: Is the TP-Link EAP110 (SKU: EAP110) suitable for guest Wi-Fi networks? A5: Yes! It features captive portal functionality, allowing secure and customizable guest Wi-Fi access.
