Elevate your wireless network with the TP-Link EAP613 (AX1800 Ceiling Mount WiFi 6 Access Point), engineered for high-performance coverage and seamless user experiences. Ideal for modern enterprises, hospitality venues, and educational facilities, the EAP613 delivers impressive WiFi 6 dual-band speeds up to 1775 Mbps, ensuring smooth connectivity even in high-density environments.
Featuring an elegant ultra-slim design (only 33.6 mm thick), the EAP613 integrates effortlessly into any ceiling or wall for a discreet, professional aesthetic. Its high-efficiency WiFi 6 technology empowers networks to handle more devices simultaneously with lower latency, thanks to advanced features like OFDMA and MU-MIMO.
This versatile access point supports both 802.3at PoE+ and passive PoE, offering flexible deployment options without the need for external power adapters. Integrated into TP-Link’s Omada SDN platform, the EAP613 provides centralized cloud management, seamless roaming for uninterrupted voice and video streams, and secure guest networking with multiple authentication options. Whether you’re building a modern office network or expanding hospitality WiFi, the TP-Link EAP613 is the ideal solution for delivering ultra-fast, reliable, and secure wireless connectivity.
What’s Included in the Box
Main Features
-
Ultra-Fast WiFi 6 Speeds: Dual-band speeds up to 1775 Mbps (574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz).
-
High-Density Capacity: Supports 250+ concurrent clients for enterprise-grade environments.
-
Elegant Ultra-Slim Design: Only 33.6 mm thick for discreet ceiling or wall installation.
-
Omada Mesh Technology: Enables wireless interconnection between APs for flexible deployment.
-
Seamless Roaming: Smooth transitions for users moving between coverage zones.
-
Flexible Power Options: Supports 802.3at PoE+, passive PoE, or 12V DC (adapter not included).
-
Enterprise Security: Offers WPA3 encryption, captive portal, VLAN segmentation, rogue AP detection, and more.
-
Centralized Cloud Management: Manage and monitor the network from anywhere via Omada SDN.
-
Wide Coverage Area: Provides wireless coverage of up to 115 m² (1250 ft²).
Detailed Specifications
| Category |
Details |
| WiFi Standard |
IEEE 802.11ax/ac/n/g/b/a |
| Frequency Bands |
2.4 GHz & 5 GHz |
| Max Speeds |
2.4 GHz: up to 574 Mbps
5 GHz: up to 1201 Mbps |
| Concurrent Clients |
250+ |
| Coverage Area |
Up to 115 m² (1250 ft²) |
| Antenna Type |
Internal Omni Antennas:
2× 4 dBi (2.4 GHz)
2× 5 dBi (5 GHz) |
| Ethernet Port |
1× Gigabit Ethernet (RJ-45) |
| PoE Standards |
802.3at PoE+
Passive PoE |
| DC Power Option |
12V / 1A DC (adapter not included) |
| Power Consumption |
11.0W (PoE)
9.9W (DC) |
| Dimensions (V2 and above) |
160 × 160 × 33.6 mm (6.3 × 6.3 × 1.3 in) |
| Security Features |
WPA3/WPA2/WPA, Captive Portal, MAC filtering, VLAN, rogue AP detection, 802.1X |
| Management Features |
Omada SDN Cloud, SNMP v1/v2c/v3, SSH, HTTP/HTTPS, Multi-site, Zero-touch provisioning |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Operating Humidity |
10–90% RH non-condensing |
| Storage Humidity |
5–90% RH non-condensing |
| Certifications |
CE, FCC, RoHS |
Warranty Information
TP-Link offers a limited warranty on the EAP613, covering manufacturing defects and hardware malfunctions. Warranty periods and terms vary by region. Customers in Australia and New Zealand can rely on authorized local channels for support and warranty claims.
Brand Description
TP-Link is a global leader in networking solutions, recognized for delivering high-quality, reliable products. From small business networks to enterprise-scale deployments, TP-Link’s innovative technologies like WiFi 6 ensure stable, high-speed connectivity across a broad range of environments.
SKU
EAP613
Practical Use Scenarios
✅ Perfect for modern offices seeking unobtrusive, high-speed ceiling-mounted WiFi.
✅ Excellent for hospitality venues such as hotels, conference centers, and restaurants where seamless roaming and secure guest networks are essential.
✅ Ideal for educational institutions requiring stable, high-capacity WiFi for classrooms, libraries, and lecture halls.
✅ Suitable for retail environments where stylish, discreet installations are needed without compromising performance.
Datasheets & Downloadable Resources
Excellence for the Australian and New Zealand Market
The TP-Link EAP613 AX1800 Ceiling Mount WiFi 6 Access Point meets stringent Australian and New Zealand standards, including CE, FCC, and RoHS certifications. It’s designed for deployment in a wide range of ANZ commercial and hospitality environments, offering reliable performance under local regulatory conditions.
All products are sourced exclusively through authorized TP-Link distributors in Australia and New Zealand, ensuring genuine devices and streamlined warranty support. Businesses can confidently deploy the EAP613, knowing that local service channels are available for quick assistance and support tailored to the unique demands of the Australian and New Zealand markets.
FAQs
Q1: What is the maximum wireless speed of the TP-Link EAP613 (SKU: EAP613)?
A1: The TP-Link EAP613 offers combined dual-band speeds up to 1775 Mbps—574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz.
Q2: Can the TP-Link EAP613 (SKU: EAP613) be managed via the cloud?
A2: Yes, the EAP613 integrates with TP-Link’s Omada SDN platform for centralized cloud-based management, monitoring, and configuration.
Q3: Does the TP-Link EAP613 (SKU: EAP613) support PoE power?
A3: Absolutely! The EAP613 supports 802.3at PoE+, passive PoE, and 12V DC power for flexible installation options.
Q4: How many devices can connect to the TP-Link EAP613 (SKU: EAP613) simultaneously?
A4: The EAP613 can handle 250+ concurrent clients, making it suitable for dense enterprise environments.
Q5: What security features does the TP-Link EAP613 (SKU: EAP613) include?
A5: It offers enterprise-grade security such as WPA3 encryption, captive portals, rogue AP detection, VLAN support, and more.
