Experience exceptional speed, flexibility, and power with the TP-Link SG3428XPP-M2, a next-generation L2+ managed switch tailored for high-performance enterprise networks, Wi-Fi 6/6E deployments, and multi-gigabit environments.

This powerful switch delivers a perfect blend of multi-gig connectivity and advanced PoE capabilities, featuring 24× 2.5G RJ45 ports—including 8 PoE++ ports supporting up to 60W per port and 16 PoE+ ports supporting up to 30W per port—allowing seamless deployment of high-power devices such as Wi-Fi 6/6E access points, IP cameras, and VoIP systems.

Its 4× 10G SFP+ uplink slots guarantee high-speed backbone connections and scalable network design. Integrated into TP-Link’s Omada SDN, the SG3428XPP-M2 offers centralized cloud management, Zero-Touch Provisioning, and advanced monitoring. Combined with robust security, QoS, multicast capabilities, and static routing, it’s the ideal solution for growing networks demanding top-tier performance and reliability.

If your business requires multi-gig throughput, future-ready PoE power, and rock-solid reliability, the SG3428XPP-M2 is your switch to unleash it all.

What's Included in the Box

• SG3428XPP-M2 Switch

• Power Cord

• Quick Installation Guide

• Rackmount Kit

• Rubber Feet

Main Features

✅ High-Performance Multi-Gig Connectivity

• 24× 2.5GBASE-T ports for high-speed networking

• Backward compatibility with 1G speeds for flexible deployment

✅ Powerful PoE Capability

• 8× PoE++ ports (up to 60W per port) for high-power devices like Wi-Fi 6/6E APs and PTZ cameras

• 16× PoE+ ports (up to 30W per port) for typical PoE devices

• Total PoE budget of 500W to power multiple devices simultaneously

✅ 10G Fiber Uplinks

• 4× 10G SFP+ slots for ultra-fast uplinks or stacking

✅ Advanced Layer 2+ and Lite Layer 3 Features

• Static routing for efficient traffic management

• Comprehensive VLAN, QoS, and multicast capabilities

✅ Robust Security

• IP-MAC-Port Binding, ACLs, DHCP Snooping, Port Security, DoS Defense, 802.1X Authentication, AAA support

✅ Centralized Omada SDN Management

• Manage multiple sites and devices through a single pane of glass, via cloud or local controllers

✅ Enterprise-Class Performance

• 200 Gbps switching capacity

• 148.80 Mpps forwarding rate ensures smooth handling of demanding traffic loads

Detailed Specifications

• Ports:

  • 24× 2.5G RJ45 ports (8 PoE++, 16 PoE+)

  • 4× 10G SFP+ slots

  • 1× RJ45 console port

  • 1× Micro-USB console port

• PoE Details:

  • PoE Standards: 802.3bt/at/af

  • PoE++ Ports (60W max per port): 8 ports

  • PoE+ Ports (30W max per port): 16 ports

  • Total PoE Budget: 500W

• Performance:

  • Switching Capacity: 200 Gbps

  • Packet Forwarding Rate: 148.80 Mpps

  • MAC Address Table: 32 K

  • Packet Buffer: 16 Mbit

  • Jumbo Frame: 9 KB

  • Max Power Consumption: 629.1 W (110V/60Hz)

  • Max Heat Dissipation: 2153.45 BTU/h

  • Fan Quantity: 3

• Layer 3 Features:

  • Up to 32 IPv4/IPv6 interfaces

  • Up to 48 static routes

  • Proxy ARP, Gratuitous ARP

  • DHCP Server and Relay support

• Layer 2 Features:

  • Static & LACP Link Aggregation

  • Spanning Tree Protocols (STP, RSTP, MSTP)

  • Loopback Detection

  • 802.3x Flow Control

  • Port and CPU Mirroring

• Multicast:

  • IGMP v1/v2/v3 Snooping

  • MLD v1/v2 Snooping

  • Multicast VLAN Registration (MVR)

  • 511 IGMP Groups supported

  • Multicast filtering with 256 profiles

• Quality of Service (QoS):

  • 8 priority queues

  • CoS/DSCP-based traffic prioritization

  • Port and flow-based rate limiting

  • QoS remarking

• Security:

  • IP-MAC-Port Binding (512 entries)

  • DHCP Snooping, ARP Inspection, Source Guard

  • DoS Defend

  • Port Isolation

  • Storm Control

  • 802.1X authentication (port and MAC-based)

  • AAA support including TACACS+

  • HTTPS and SSH secure management

• VLAN Support:

  • Up to 4,000 VLAN groups

  • MAC VLAN

  • Protocol VLAN

  • Private VLAN

  • QinQ VLAN VPN

• Management:

  • Web GUI

  • CLI via console, Telnet, SSH

  • SNMP v1/v2c/v3, RMON support

  • Omada SDN centralized management

  • Zero-Touch Provisioning

  • Dual Image & Dual Configuration

  • Cable diagnostics

  • EEE support

• Physical & Environmental:

  • Dimensions: 17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm)

  • Operating temperature: 0–40°C

  • Operating humidity: 10–90% RH non-condensing

• Certifications: CE, FCC, RoHS

Warranty Information

• Manufacturer’s Limited Warranty

About TP-Link Omada

The TP-Link Omada series empowers businesses with next-generation networking solutions, offering high performance, simplified centralized management, and outstanding scalability for networks of any size.

SKU

SG3428XPP-M2

Practical Use Scenarios

• Wi-Fi 6/6E Deployments: Perfect for powering high-performance access points requiring multi-gig speeds and higher PoE budgets

• Enterprise Edge Switching: A robust core for mid-sized networks demanding high throughput and advanced management

• IP Surveillance Systems: High PoE budget supports numerous high-power cameras

• Hospitality or Retail Environments: Supports seamless device connectivity and centralized network management

Datasheets or Downloadable Resources

Download SG3428XPP-M2 Datasheet

Excellence for the Australian and New Zealand Market

The TP-Link SG3428XPP-M2 is fully compliant with Australian and New Zealand regulatory standards, sourced via official channels to ensure genuine hardware, local warranty support, and compatibility with ANZ networking environments. Enjoy peace of mind knowing your investment meets regional compliance and quality standards.

FAQs (SG3428XPP-M2)

Q1: What’s the difference between PoE++ and PoE+ on the SG3428XPP-M2?
A1: PoE++ ports deliver up to 60W per port for high-power devices like Wi-Fi 6/6E APs or PTZ cameras, while PoE+ provides up to 30W per port. (SG3428XPP-M2)

Q2: Can I manage the SG3428XPP-M2 through the cloud?
A2: Yes! The switch fully integrates into the Omada SDN platform, offering centralized cloud management, monitoring, and Zero-Touch Provisioning. (SG3428XPP-M2)

Q3: How many devices can the 500W PoE budget support?
A3: The exact number varies based on device power requirements. For example, eight PoE++ ports at max load (60W) would consume 480W, leaving budget for additional lower-power devices on PoE+ ports. (SG3428XPP-M2)

Q4: Does the SG3428XPP-M2 support stacking?
A4: It doesn’t support physical stacking but can be logically managed alongside other Omada switches via Omada SDN for unified control. (SG3428XPP-M2)

Q5: Is this switch suitable for high-bandwidth applications like Wi-Fi 6/6E?
A5: Absolutely! The SG3428XPP-M2 offers 2.5G ports ideal for multi-gig Wi-Fi APs and 10G uplinks for smooth aggregation. (SG3428XPP-M2)
