Upgrade enterprise networks with the robust TP-Link SG3452P, a 52-port Gigabit L2+ managed switch built for high-performance, power delivery, and advanced Layer 3 capabilities. Equipped with 48× Gigabit PoE+ ports, each delivering up to 30W of power, it effortlessly supports Wi-Fi 6 APs, VoIP phones, and IP cameras while maintaining a total PoE budget of 384W. An additional 4× Gigabit SFP slots offer flexible uplinks for fiber expansion, aggregation, or redundant links.

With a switching capacity of 104 Gbps and a forwarding rate of 77.38 Mpps, the SG3452P ensures smooth data transfers and reliable network operations. Seamlessly integrate this switch into TP-Link’s Omada SDN platform, allowing centralized cloud management, remote monitoring, zero-touch provisioning, and intelligent diagnostics—all accessible via a user-friendly web interface or the Omada app.

Packed with enterprise-grade L2/L3 features, sophisticated security, QoS controls, and dual image support, the SG3452P delivers exceptional scalability and stability for business-critical networks across enterprises, hospitality, retail, and campus deployments.

What's Included in the Box

• SG3452P Switch

• Power Cord

• Quick Installation Guide

• Rackmount Kit

• Rubber Feet

Main Features

✅ PoE+ Power for Smart Networks

• 48× PoE+ ports (up to 30W per port) ideal for powering access points, cameras, and VoIP

✅ Generous PoE Budget

• Delivers up to 384W total PoE power, supporting dense device deployments

✅ Flexible Uplinks

• 4× Gigabit SFP slots provide flexible fiber or copper uplink options

✅ High Performance & Reliability

• 104 Gbps switching capacity and 77.38 Mpps forwarding for non-blocking performance

✅ Omada SDN Integration

• Unified management, monitoring, and zero-touch deployment via cloud controllers

✅ Robust L2+/L3 Features

• VLANs, static routing, IGMP Snooping, security policies, and advanced QoS for precise network control

✅ Enterprise-Grade Design

• Durable metal chassis, rack-mountable form factor, and 3 smart fans for cooling

Detailed Specifications

• Ports & Interfaces:

  • 48× 10/100/1000 Mbps PoE+ RJ45 Ports

  • 4× Gigabit SFP Slots

  • 1× RJ45 Console Port

  • 1× Micro-USB Console Port

• Performance:

  • Switching Capacity: 104 Gbps

  • Packet Forwarding Rate: 77.38 Mpps

  • MAC Address Table: 16 K

  • Packet Buffer Memory: 12 Mbit

  • Jumbo Frame: 9 KB

• PoE Capabilities:

  • Standard: 802.3af/at compliant

  • PoE+ Ports: 48 (up to 30W per port)

  • Total Power Budget: 384W

• Power & Environment:

  • Fan Quantity: 3

  • Max Power Consumption: 464.2 W (with 384W PD connected)

  • Max Heat Dissipation: 1584.08 BTU/hr

  • Operating Temperature: 0–40 ℃

  • Storage Temperature: -40–70 ℃

• Layer 2 and Layer 3 Features:

  • Static Routing: 48 IPv4/IPv6 static routes

  • Static ARP (128 entries), 316 ARP entries total

  • Proxy ARP, Gratuitous ARP

  • DHCP Server, Relay, L2 Relay

  • Link Aggregation (Static and LACP)

  • Spanning Tree Protocol (STP, RSTP, MSTP)

  • Loopback Detection

  • 802.3x Flow Control

  • Port Mirroring

• L2 Multicast:

  • IGMP Snooping v1/v2/v3

  • MLD Snooping v1/v2

  • Multicast VLAN Registration (MVR)

  • Multicast Filtering: 256 profiles, 16 entries per profile

• Quality of Service (QoS):

  • 8 priority queues

  • 802.1p CoS/DSCP priority

  • Bandwidth control

  • QoS remarking

• Security:

  • IP-MAC-Port Binding (512 entries)

  • DHCP Snooping, ARP Inspection

  • IPv4 Source Guard

  • IPv6 MAC-Port Binding, ND detection

  • DoS Defend

  • Static/Dynamic Port Security (up to 64 MACs per port)

  • Storm Control

  • 802.1X authentication

  • AAA (including TACACS+)

  • Secure web management (HTTPS) and CLI (SSH)

• VLAN Support:

  • Up to 4,000 VLAN groups

  • MAC VLAN: 48 entries

  • Protocol VLAN: 16 templates

  • Private VLAN, GVRP

  • VLAN VPN (QinQ)

  • Voice VLAN

• ISP Features:

  • L2PT

  • DLDP

  • PPPoE ID Insertion

  • ERPS

  • 802.3ah Ethernet OAM

• Management:

  • Web-based GUI

  • CLI via console, Telnet, SSH

  • SNMP v1/v2c/v3, RMON (1,2,3,9 groups)

  • Omada Cloud-Based Controller

  • Zero-Touch Provisioning

  • Cable Diagnostics

  • Dual Image and Dual Configuration

• Certifications: CE, FCC, RoHS

Warranty Information

• Manufacturer’s Limited Warranty

About TP-Link Omada

TP-Link Omada SDN redefines network management with seamless integration, scalable deployments, and intelligent monitoring—all controlled through a unified cloud interface. Trusted by businesses worldwide for reliable, high-performance networking solutions.

SKU

SG3452P

Practical Use Scenarios

• Large Office Networks: Perfect for powering VoIP phones, Wi-Fi 6 APs, and IP cameras with robust PoE support.

• Hospitality and Retail: Supports surveillance, guest Wi-Fi, and PoS systems with high PoE density.

• Campus Networks: Offers reliable fiber uplinks for inter-building connectivity.

• Managed Service Providers: Delivers advanced VLAN, security, and management features for client networks.

Datasheets or Downloadable Resources

Download SG3452P Datasheet

Excellence for the Australian and New Zealand Market

The SG3452P is CE, FCC, and RoHS certified, ensuring full compliance with Australian and New Zealand regulations. Sourced exclusively through authorized channels, it guarantees authentic TP-Link quality, local warranty support, and reliable technical assistance.

FAQs (SG3452P)

Q1: How much PoE power budget does the SG3452P provide?
A1: The SG3452P offers a total PoE budget of 384W, with up to 30W available per PoE+ port. (SG3452P)

Q2: Can the SG3452P be managed through the cloud?
A2: Yes! The SG3452P integrates with TP-Link’s Omada SDN for cloud-based management and monitoring. (SG3452P)

Q3: What type of uplinks does the SG3452P support?
A3: The switch includes 4× Gigabit SFP slots for flexible fiber or copper uplinks. (SG3452P)

Q4: Does the SG3452P support VLAN configurations?
A4: Absolutely. It supports up to 4,000 VLAN groups, including QinQ, GVRP, and Voice VLANs. (SG3452P)

Q5: What is the switching capacity of the SG3452P?
A5: The SG3452P boasts a 104 Gbps switching capacity to handle high network loads efficiently. (SG3452P)
