Expand your network with confidence using the TP-Link TL-SG1016 16-Port Gigabit Rackmount Switch, designed to deliver reliable high-speed connectivity for businesses, workgroups, and growing networks. Equipped with 16 high-speed 10/100/1000Mbps RJ45 ports, this robust switch offers a substantial 32 Gbps switching capacity, ensuring smooth, uninterrupted data flow for demanding applications.
Perfect for connecting servers, workstations, network storage, IP cameras, VoIP systems, and other high-bandwidth devices, the TL-SG1016 provides enterprise-level performance without complexity. Its Plug and Play design means you can deploy it instantly—no configuration or technical expertise required.
The TL-SG1016 incorporates advanced energy-efficient technology, which automatically adjusts power consumption based on link status and cable length, reducing electricity costs and environmental impact while maintaining peak performance.
With a fanless design, the TL-SG1016 ensures silent operation, ideal for noise-sensitive environments like offices, studios, or classrooms. Encased in a durable standard 19-inch rack-mountable steel chassis, it offers professional aesthetics and physical protection for mission-critical network infrastructure.
Additional features such as MAC address self-learning, Auto MDI/MDIX, and support for jumbo frames up to 10KB improve network efficiency and simplify management. For enhanced control and security, newer hardware versions (V12 and above) include 802.1p/DSCP QoS for traffic prioritization, along with port isolation and loop prevention to maintain stable and secure network operations.
Whether you’re upgrading your business network or setting up a high-performance environment, the TL-SG1016 is an excellent choice for reliable and efficient Gigabit connectivity.
What’s Included in the Box
Main Features
✅ 16 Gigabit Ports – Delivers reliable high-speed connections for multiple devices in office and business networks.
✅ High Switching Capacity – 32Gbps switching capacity ensures stable performance for demanding applications.
✅ Energy-Efficient Technology – Reduces power consumption without sacrificing performance, saving operational costs.
✅ Silent Fanless Operation – Operates silently, perfect for noise-sensitive environments.
✅ Plug and Play Installation – Requires no configuration, allowing easy and fast deployment.
✅ MAC Address Self-Learning – Simplifies network management and enhances performance.
✅ Advanced Network Features – Includes port isolation, loop prevention, and QoS (on V12 and later) for secure and optimized networking.
✅ Rackmount-Ready Design – Standard 19-inch steel housing ensures durability and professional integration into network racks.
✅ Jumbo Frame Support – Handles large data transfers up to 10KB for increased efficiency.
Detailed Specifications
-
Model: TL-SG1016
-
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
-
Ports: 16 × 10/100/1000Mbps RJ45 ports (Auto Negotiation, Auto MDI/MDIX)
-
Network Media:
-
10BASE-T: UTP Cat3, 4, 5 cables (max 100m)
-
100BASE-TX/1000BASE-T: UTP Cat5, 5e or above cables (max 100m)
-
Fan Quantity: Fanless
-
Physical Security Lock: No
-
Power Supply: 100-240VAC, 50/60Hz
-
Max. Power Consumption: 10.4W
-
Max. Heat Dissipation: 35.6 BTU/h
-
Dimensions (W × D × H): 440 × 180 × 44 mm (17.3 × 7.1 × 1.7 in.)
-
Mounting: Rack mountable (brackets included)
-
Performance:
-
Switching Capacity: 32Gbps
-
Packet Forwarding Rate: 23.8Mpps
-
MAC Address Table: 8K entries
-
Jumbo Frame Support: 10KB
-
Advanced Features:
-
Isolation Mode: Ports 1–14
-
Loop Prevention: Ports 1–16
-
QoS (802.1p/DSCP) on V12 and later hardware versions
-
Green Technology: Yes
-
Transmission Method: Store-and-Forward
-
Certifications: FCC, RoHS
-
Operating Environment:
-
Temperature: 0–40°C (32–104°F)
-
Storage Temperature: -40–70°C (-40–158°F)
-
Operating Humidity: 10–90% RH non-condensing
-
Storage Humidity: 5–90% RH non-condensing
Warranty Information
The TL-SG1016 is backed by TP-Link’s limited warranty, covering defects in materials and workmanship. Warranty services are provided through authorized TP-Link partners, ensuring reliable support and peace of mind.
About TP-Link
Founded in 1996, TP-Link has become a global leader in networking technology, trusted by millions for delivering innovative and reliable solutions. From small business networks to enterprise-grade infrastructure, TP-Link keeps users connected efficiently and securely.
SKU
TL-SG1016
Practical Use Scenarios
-
Small to Medium Businesses: Connect office PCs, printers, and servers with high-speed, stable networking.
-
Data Workgroups: Facilitate fast file transfers between workstations for collaborative projects.
-
Educational Institutions: Provide robust network connectivity for classrooms, labs, and administrative offices.
-
Video Surveillance Networks: Support multiple IP cameras and NVRs with stable Gigabit links.
-
Retail and Hospitality: Maintain seamless connections for POS systems, back-office operations, and customer networks.
Datasheets / Downloadable Resources
Download TP-Link TL-SG1016 Datasheet
Excellence for the Australian and New Zealand Market
The TP-Link TL-SG1016 16-Port Gigabit Rackmount Switch fully complies with Australian and New Zealand standards, certified under FCC and RoHS for performance and environmental safety. Tailored for the region’s unique networking requirements, this model is distributed through authorized TP-Link partners, ensuring genuine products and local support. All warranty claims and technical assistance are managed directly by TP-Link or its authorized partners, offering fast and dependable service for customers across Australia and New Zealand.
FAQs
Q1: Does the TP-Link TL-SG1016 (TL-SG1016) support jumbo frames?
Yes, the TL-SG1016 supports jumbo frames up to 10KB, which helps optimize large data transfers for business applications.
Q2: Is the TP-Link TL-SG1016 (TL-SG1016) noisy during operation?
No. The TL-SG1016 has a fanless design, ensuring silent operation suitable for noise-sensitive environments.
Q3: What is the switching capacity of the TP-Link TL-SG1016 (TL-SG1016)?
The TL-SG1016 offers a switching capacity of 32Gbps, supporting smooth data transmission across all ports.
Q4: Does the TP-Link TL-SG1016 (TL-SG1016) require any configuration?
No. The TL-SG1016 is Plug and Play, requiring no configuration for basic operation.
Q5: Is the TP-Link TL-SG1016 (TL-SG1016) compliant for use in Australia and New Zealand?
Yes, the TL-SG1016 meets all relevant standards and is available through authorized channels in Australia and New Zealand, ensuring warranty support and local service.
