Upgrade your network infrastructure with the TP-Link TL-SG1024 24-Port Gigabit Rackmount Switch, engineered for businesses, offices, and enterprise environments demanding high-capacity, stable, and efficient connectivity. Boasting 24 high-speed 10/100/1000Mbps RJ45 ports, this robust switch delivers an impressive 48 Gbps switching capacity, ensuring fast and reliable data transfers for high-bandwidth applications.
Whether you’re connecting servers, workstations, IP cameras, VoIP systems, or network storage devices, the TL-SG1024 provides the performance and scalability essential for modern networks. Its Plug and Play design simplifies deployment, requiring no software configuration, allowing your network to be operational in minutes.
Equipped with innovative energy-efficient technology, the TL-SG1024 intelligently adjusts power consumption based on link status and cable length, reducing power usage without sacrificing performance—ideal for businesses looking to lower operational costs while minimizing environmental impact.
The switch’s fanless design guarantees silent operation, perfect for offices, workspaces, and noise-sensitive environments. With a rugged standard 19-inch rack-mountable steel case, it offers both durability and seamless integration into existing rack systems.
Enhanced features like MAC address self-learning, Auto MDI/MDIX, and jumbo frame support ensure the TL-SG1024 provides enterprise-class reliability and flexibility. For even greater performance, newer hardware versions support 802.1p/DSCP QoS, enabling smoother traffic prioritization for critical applications like voice and video streaming.
The TP-Link TL-SG1024 is the ideal solution for businesses seeking a cost-effective, high-density, and dependable Gigabit networking backbone.
What’s Included in the Box
Main Features
✅ 24 Gigabit Ports – Connect multiple devices with 10/100/1000Mbps auto-negotiation for versatile, high-speed networking.
✅ High Switching Capacity – 48Gbps switching capacity ensures smooth data transfer even under heavy network loads.
✅ Energy-Efficient Technology – Reduces power consumption automatically, saving on operational costs.
✅ Fanless Silent Operation – Ensures completely silent performance, ideal for noise-sensitive environments.
✅ MAC Address Self-Learning – Simplifies network management and optimizes performance.
✅ Auto MDI/MDIX – Eliminates the need for crossover cables for easier deployment.
✅ Rackmount-Ready – Standard 19-inch steel case integrates seamlessly into professional network racks.
✅ Jumbo Frame Support – Enhances large data transfers for high-performance applications.
Detailed Specifications
-
Model: TL-SG1024
-
Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
-
Ports: 24 × 10/100/1000Mbps RJ45 ports (Auto Negotiation, Auto MDI/MDIX)
-
Network Media:
-
10BASE-T: UTP Cat3, 4, 5 cable (max 100m)
-
100BASE-TX/1000BASE-T: UTP Cat5, 5e or above cable (max 100m)
-
Fan Quantity: Fanless
-
Physical Security Lock: No
-
Power Supply: 100-240VAC, 50/60Hz
-
Dimensions (W × D × H): 440 × 180 × 44 mm (17.3 × 7.1 × 1.7 in.)
-
Mounting: 19” rack mountable (mounting brackets included)
-
Max. Power Consumption: 13.6W
-
Max. Heat Dissipation: 46.4 BTU/h
-
Performance:
-
Switching Capacity: 48Gbps
-
Packet Forwarding Rate: 35.7Mpps
-
MAC Address Table: 8K entries
-
Buffer Memory: 1.5Mb
-
Jumbo Frame Support: 10KB
-
QoS Support: 802.1p/DSCP (V11 and later versions only)
-
Green Technology: Yes
-
Transmission Method: Store-and-Forward
-
Certifications: FCC, CE, RoHS
-
Operating Environment:
-
Temperature: 0–40°C (32–104°F)
-
Storage Temperature: -40–70°C (-40–158°F)
-
Operating Humidity: 10–90% RH non-condensing
-
Storage Humidity: 5–90% RH non-condensing
Warranty Information
The TL-SG1024 is backed by TP-Link’s limited warranty, covering defects in materials and workmanship. Warranty services are managed through authorized TP-Link partners to ensure fast and reliable support.
About TP-Link
Founded in 1996, TP-Link has become a global leader in networking technology, renowned for delivering innovative, high-performance products for both home and enterprise networks. Trusted by millions worldwide, TP-Link is dedicated to keeping people and businesses reliably connected.
SKU
TL-SG1024
Practical Use Scenarios
-
Small to Medium Businesses: Build a reliable network backbone for connecting multiple computers, printers, and servers.
-
Data Centers: Handle large volumes of data with high-speed, high-density port availability.
-
Educational Institutions: Provide stable connectivity for classrooms, labs, and administrative offices.
-
Video Surveillance Networks: Support large-scale deployments of IP cameras and NVRs.
-
Retail and Hospitality: Connect POS systems, back-office devices, and guest networks seamlessly.
Datasheets / Downloadable Resources
Download TP-Link TL-SG1024 Datasheet
Excellence for the Australian and New Zealand Market
The TP-Link TL-SG1024 24-Port Gigabit Rackmount Switch is fully compliant with Australian and New Zealand standards, certified under FCC, CE, and RoHS for safety and performance. Tailored for the specific networking needs of these regions, this model is distributed exclusively through authorized TP-Link partners, guaranteeing genuine products and reliable local support. All warranty claims and technical services are handled directly through TP-Link or its authorized partners, ensuring fast, dependable service for customers across Australia and New Zealand.
FAQs
Q1: Does the TP-Link TL-SG1024 (TL-SG1024) support jumbo frames for large file transfers?
Yes, the TL-SG1024 supports jumbo frames up to 10KB, improving efficiency for large data transfers.
Q2: Is the TP-Link TL-SG1024 (TL-SG1024) noisy during operation?
No. The TL-SG1024 features a fanless design, ensuring completely silent operation—perfect for noise-sensitive environments.
Q3: What is the switching capacity of the TP-Link TL-SG1024 (TL-SG1024)?
The TL-SG1024 delivers a switching capacity of 48Gbps, ensuring fast and stable performance even during peak network usage.
Q4: Does the TP-Link TL-SG1024 (TL-SG1024) require software configuration?
No. The TL-SG1024 is an unmanaged switch, offering Plug and Play convenience with no software setup required.
Q5: Is the TP-Link TL-SG1024 (TL-SG1024) certified for use in Australia and New Zealand?
Yes, the TL-SG1024 complies with all relevant Australian and New Zealand standards and is available through authorized channels to ensure warranty support and local service.
