Upgrade your business or office network effortlessly with the TP-Link TL-SG1024DE, a high-performance 24-Port Gigabit Easy Smart Switch designed to simplify network management while delivering exceptional speed and reliability.

Featuring 24 Gigabit RJ45 ports, the TL-SG1024DE supports blazing-fast data transfer rates and offers advanced management features like VLANs, QoS, and IGMP Snooping to optimize network performance and traffic segmentation. Whether you’re prioritizing VoIP, video streaming, or essential business data, this switch ensures smooth, stable communication.

The fanless design guarantees silent operation, ideal for noise-sensitive environments. Thanks to TP-Link’s green technology, the switch automatically adjusts power consumption based on cable length and link status, reducing operational costs without sacrificing performance.

With plug-and-play simplicity and an intuitive web-based user interface, the TL-SG1024DE delivers flexible control for small and medium businesses seeking enhanced network visibility and efficiency.

What's in the Box

• TL-SG1024DE Switch

• Power Cord

• Rackmount Kit

• Rubber Feet

• Installation Guide

• Resource CD

Main Features

✅ 24 Gigabit Ports for High-Speed Networking – Supports up to 1000 Mbps for seamless data transfer.

✅ Advanced Network Management – VLAN, QoS, IGMP Snooping, and more for professional-grade network optimization.

✅ Energy-Efficient Operation – Green technology reduces power consumption and saves costs.

✅ Silent, Fanless Design – Perfect for noise-sensitive office environments.

✅ Plug-and-Play Simplicity – Quick setup with optional web-based configuration for fine-tuning.

✅ Compact Rackmount Design – Fits seamlessly into standard 19” racks for neat installations.

Detailed Specifications

Hardware:

• 24 × 10/100/1000 Mbps RJ45 Ports

• Auto-Negotiation / Auto MDI/MDIX

• Fanless Design

• Power Supply: 100–240V AC, 50/60Hz

• Dimensions: 11.6 x 7.1 x 1.7 in (294 x 180 x 44 mm)

• Max Power Consumption: 14.19 W

• Max Heat Dissipation: 48.39 BTU/h

Performance:

• Switching Capacity: 48 Gbps

• Packet Forwarding Rate: 35.7 Mpps

• MAC Address Table: 8K

• Packet Buffer Memory: 4.1 Mbit

• Jumbo Frame: 10 KB

Software Features:

• Quality of Service (QoS)

  • Port-Based / 802.1p / DSCP Priority

  • 4 Priority Queues

  • Rate Limit

  • Storm Control

• L2 Features:

  • IGMP Snooping V1/V2/V3

  • Static Link Aggregation

  • Port Mirroring

  • Cable Diagnostics

  • Loop Prevention

• VLAN:

  • Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)

  • MTU / Port / Tag VLAN

• Transmission Method: Store-and-Forward

Certifications: FCC, CE, RoHS

System Requirements: Microsoft® Windows® for Easy Smart Utility

Environmental:

• Operating Temperature: 0–40 ℃ (32–104 ℉)

• Storage Temperature: -40–70 ℃ (-40–158 ℉)

• Operating Humidity: 10–90% RH non-condensing

• Storage Humidity: 5–90% RH non-condensing

Warranty Information

Backed by TP-Link’s manufacturer warranty, providing peace of mind for business installations. Check with your local distributor for warranty specifics.

Brand Description

TP-Link is a leading global provider of networking solutions, offering innovative and reliable products for homes and businesses alike. Trusted worldwide, TP-Link delivers high-performance networking gear tailored to modern connectivity needs.

SKU

TL-SG1024DE

Practical Use Scenarios

• Small to Medium Businesses – Centralized network management with traffic prioritization.

• Video Conferencing – Smooth, lag-free meetings with QoS prioritization.

• Office Networks – Segregate traffic and improve security using VLANs.

• Educational Institutions – Manage bandwidth and ensure stable network performance.

• Surveillance Systems – Handle high-volume data transfer for IP cameras.

Datasheets / Downloadable Resources

Download TL-SG1024DE Datasheet

Excellence for the Australian and New Zealand Market

The TP-Link TL-SG1024DE meets Australian and New Zealand electrical and communication standards and is sourced via authorized local distributors. Customers enjoy dedicated regional support, compliance assurance, and warranty handling for complete peace of mind in enterprise and commercial installations.

FAQs

Q1. Does the TL-SG1024DE support VLANs for network segmentation? (TL-SG1024DE)
Yes, the TL-SG1024DE supports up to 32 VLANs simultaneously, allowing you to isolate network segments for security and performance.

Q2. Can I use the TL-SG1024DE for video streaming applications? (TL-SG1024DE)
Absolutely! It offers advanced QoS features to prioritize video traffic, ensuring smooth and lag-free streaming.

Q3. Is the TL-SG1024DE noisy? (TL-SG1024DE)
No, it has a fanless design for completely silent operation, perfect for quiet office environments.

Q4. Does the TL-SG1024DE require complex configuration? (TL-SG1024DE)
No complex setup is required. It’s plug-and-play but offers a web-based GUI and management utility for additional customization if desired.

Q5. How much power does the TL-SG1024DE consume? (TL-SG1024DE)
The TL-SG1024DE has a maximum power consumption of only 14.19W, making it an energy-efficient choice for business networks.
