The Uniview NVR804-16-IX-G 16 Channel IX Series SeekFree Network Video Recorder delivers powerful enterprise-grade surveillance performance with 4K recording, Ultra H.265 compression, AI analytics, and advanced video metadata capabilities. Designed for professional security systems, this high-performance NVR supports up to 16 IP cameras, intelligent analytics such as face detection and people counting, RAID storage, and 384 Mbps bandwidth, making it ideal for commercial, retail, industrial, and large residential deployments.

Product Description

The Uniview NVR804-16-IX-G IX Series Network Video Recorder is a powerful and intelligent surveillance management solution designed to support modern AI-driven security systems. Built for reliability and high-performance video processing, this professional NVR supports Ultra 265, H.265, and H.264 video compression, allowing efficient storage usage without compromising image quality.

With support for up to 16 IP camera channels, the device can record and manage up to 4K resolution video, ensuring crystal-clear monitoring and playback. The integrated SeekFree technology enables intelligent video search and enhanced compatibility with both Uniview and third-party cameras, making it highly flexible for mixed surveillance environments.

This NVR also includes advanced AI features such as face detection, plate comparison, people counting, behaviour analysis, and video metadata analytics, allowing businesses to gain deeper insights from surveillance footage. With multiple HDMI outputs, RAID storage capability, and up to 384 Mbps bandwidth, the system is engineered for demanding professional security applications.

Designed for scalable deployments, the NVR804-16-IX-G also supports ANR (Automatic Network Replenishment) to maintain recording integrity during network interruptions, ensuring reliable surveillance recording at all times.

What’s Included in the Box

• 1 × Uniview NVR804-16-IX-G Network Video Recorder

• 1 × Power Cable

• 1 × Mouse

• 1 × Quick Installation Guide

• Mounting Accessories
  (Hard Drives not included)

Main Features

• Supports 16 IP camera channels

• Ultra 265 / H.265 / H.264 video compression

• 4K UHD recording and HDMI output

• SeekFree intelligent video search

• Advanced AI analytics including face detection, behaviour analysis and people counting

• 384 Mbps incoming and outgoing bandwidth

• RAID 0 / 1 / 5 storage support for enhanced data protection

• ANR technology for recording continuity during network loss

• 3 HDMI outputs and 1 VGA output

• Supports up to 4 SATA HDDs (24TB per drive)

• Compatible with Uniview and third-party ONVIF cameras

• Cloud upgrade support

• Multiple smart analytics including video metadata and vehicle detection

Detailed Specifications

Model: NVR804-16-IX-G
Product Type: Network Video Recorder (NVR)

Video & Decoding

• Video Compression: Ultra 265, H.265, H.264

• Max Recording Resolution: 32MP

• Decoding Capability:

  • 6 × 4K @30fps

  • 8 × 6MP @30fps

  • 10 × 5MP @30fps

  • 16 × 1080P @30fps

Camera Input

• IP Camera Input: 16 Channels

Bandwidth

• Incoming Bandwidth: 384 Mbps

• Outgoing Bandwidth: 384 Mbps

Video Output

• HDMI Output: 3 Ports

• VGA Output: 1 Port

• HDMI Resolution: Up to 4K (3840×2160)

• VGA Resolution: Up to 1080p

Storage

• HDD Bays: 4 SATA Ports

• Max Capacity: 24TB per HDD

• RAID Support: RAID 0 / 1 / 5

Playback

• Max Concurrent Playback: 32 Channels

• Local Synchronous Playback: 16 Channels

Smart Analytics

• Face Detection

• Face Comparison

• Smart Intrusion Prevention (SIP)

• Video Metadata Analytics

• Plate Comparison

• Behaviour Analysis

• People Counting

• Crowd Density Monitoring

• Vehicle Detection

• AcuSearch & AcuTrack

Alarm & Interfaces

• Alarm Input: 16 Channels

• Alarm Output: 10 Channels

• Audio Input: 1 RCA

• Audio Output: 3 RCA

• USB:

  • Front: 2 × USB 2.0

  • Rear: 2 × USB 3.0

Network

• Ethernet: 2 × Gigabit RJ45 ports

• Protocols Supported:

  • TCP/IP

  • RTSP

  • HTTP / HTTPS

  • DHCP

  • NTP

  • SMTP

  • SNMP

  • DDNS

  • IPv4 / IPv6

Operating Conditions

• Operating Temperature: -10°C to 55°C

• Humidity: ≤90% RH (non-condensing)

Power

• Power Supply: AC 220V

• Power Consumption: ≤50W (without HDD)

Certifications

• CE

• FCC

• UL

• RoHS

• WEEE

• NDAA Compliant

Warranty Information

This product includes a 3-Year Manufacturer Warranty, ensuring dependable performance and professional support. Warranty claims and technical assistance are handled directly with authorized Uniview distributors.

Brand Information – Uniview

Uniview (UNV) is a globally recognized manufacturer of professional video surveillance products and AI-powered security technologies. Known for innovation in IP video surveillance, smart analytics, and intelligent security solutions, Uniview provides reliable systems trusted across commercial, industrial, and government security deployments worldwide.

SKU

NVR804-16-IX-G

Practical Use Scenarios

• Retail store security and loss prevention

• Commercial building surveillance systems

• Warehouses and logistics monitoring

• Schools and educational campuses

• Industrial facilities and factories

• Apartment complexes and gated communities

• Large residential surveillance systems

Datasheets / Downloadable Resources

• Datasheet UNV NVR804-IX-G Series Network Video Recorder 20251225-EN(Public)

  UNV-Network Video Recorders User Manual

Excellence for the Australian and New Zealand Market

The Uniview NVR804-16-IX-G is supplied through authorized distribution channels, ensuring genuine products designed for the Australian and New Zealand surveillance market. These systems comply with international quality standards including CE, FCC, UL, RoHS, and NDAA compliance.

Products are sourced directly from official brand representatives, guaranteeing authenticity, firmware compatibility, and reliable long-term performance. Warranty and technical support are handled through official distribution networks, ensuring customers across Australia and New Zealand receive dependable service and product support.

FAQs – Uniview NVR804-16-IX-G

What cameras are compatible with the NVR804-16-IX-G?

The NVR804-16-IX-G supports Uniview IP cameras as well as third-party ONVIF-compatible cameras, allowing flexible integration into existing surveillance systems.

Does the NVR804-16-IX-G include a hard drive?

No, the NVR804-16-IX-G is supplied without HDD, allowing installers to select storage capacity according to system requirements.

What is the maximum storage capacity of the NVR804-16-IX-G?

The NVR804-16-IX-G supports up to 4 SATA hard drives, with a maximum capacity of 24TB per drive.

Does the NVR804-16-IX-G support 4K recording?

Yes, the NVR804-16-IX-G supports recording and output up to 4K resolution, delivering ultra-high-definition surveillance footage.

Can the NVR804-16-IX-G perform AI video analytics?

Yes, the NVR804-16-IX-G supports advanced AI features such as face detection, people counting, video metadata analysis, behaviour detection, and plate comparison.

How many users can access the NVR804-16-IX-G remotely?

The NVR804-16-IX-G supports up to 128 remote users, making it suitable for large surveillance management systems.

Does the NVR804-16-IX-G support RAID storage?

Yes, the NVR804-16-IX-G supports RAID 0, RAID 1, and RAID 5, providing improved storage reliability and redundancy.
